Cilindros hidráulicos

12 subcategorías · 1.277 productos

Cilindros hidráulicos de doble efecto de Ø25 a Ø100 mm, con distintos tipos de fijación.

← Todas las categorías

Cilindro hidráulico — serie ST 166

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	S
ORK-ST0250160050	25X32X16X150X50	25	16	50	32	150	25	22	3/8”	22
ORK-ST0250160100	25X32X16X200X100	25	16	100	32	200	25	22	3/8”	22
ORK-ST0250160150	25X32X16X250X150	25	16	150	32	250	25	22	3/8”	22
ORK-ST0250160200	25X32X16X300X200	25	16	200	32	300	25	22	3/8”	22
ORK-ST0320200050	32X40X20X180X50	32	20	50	40	180	40	24	3/8”	22
ORK-ST0320200100	32X40X20X230X100	32	20	100	40	230	40	24	3/8”	22
ORK-ST0320200150	32X40X20X280X150	32	20	150	40	280	40	24	3/8”	22
ORK-ST0320200200	32X40X20X330X200	32	20	200	40	330	40	24	3/8”	22
ORK-ST0320200250	32X40X20X380X250	32	20	250	40	380	40	24	3/8”	22
ORK-ST0320200300	32X40X20X430X300	32	20	300	40	430	40	24	3/8”	22
ORK-ST0320200400	32X40X20X530X400	32	20	400	40	530	40	24	3/8”	22
ORK-ST0320200500	32X40X20X630X500	32	20	500	40	630	40	24	3/8”	22
ORK-ST0400200100	40X50X20X230X100	40	20	100	50	230	40	24	3/8”	22
ORK-ST0400200150	40X50X20X280X150	40	20	150	50	280	40	24	3/8”	22
ORK-ST0400200200	40X50X20X330X200	40	20	200	50	330	40	24	3/8”	22
ORK-ST0400200250	40X50X20X380X250	40	20	250	50	380	40	24	3/8”	22
ORK-ST0400200300	40X50X20X430X300	40	20	300	50	430	40	24	3/8”	22
ORK-ST0400200350	40X50X20X480X350	40	20	350	50	480	40	24	3/8”	22
ORK-ST0400200400	40X50X20X530X400	40	20	400	50	530	40	24	3/8”	22
ORK-ST0400200450	40X50X20X580X450	40	20	450	50	580	40	24	3/8”	22
ORK-ST0400200500	40X50X20X630X500	40	20	500	50	630	40	24	3/8”	22
ORK-ST0400250100	40X50X25X230X100	40	25	100	50	230	40	24	3/8”	22
ORK-ST0400250150	40X50X25X280X150	40	25	150	50	280	40	24	3/8”	22
ORK-ST0400250200	40X50X25X330X200	40	25	200	50	330	40	24	3/8”	22
ORK-ST0400250250	40X50X25X380X250	40	25	250	50	380	40	24	3/8”	22
ORK-ST0400250300	40X50X25X430X300	40	25	300	50	430	40	24	3/8”	22
ORK-ST0400250350	40X50X25X480X350	40	25	350	50	480	40	24	3/8”	22
ORK-ST0400250400	40X50X25X530X400	40	25	400	50	530	40	24	3/8”	22
ORK-ST0400250450	40X50X25X580X450	40	25	450	50	580	40	24	3/8”	22
ORK-ST0400250500	40X50X25X630X500	40	25	500	50	630	40	24	3/8”	22
ORK-ST0400250550	40X50X25X680X550	40	25	550	50	680	40	24	3/8”	22
ORK-ST0400250600	40X50X25X730X600	40	25	600	50	730	40	24	3/8”	22
ORK-ST0500250100	50X60X25X240X100	50	25	100	60	240	45	24	3/8”	22
ORK-ST0500250150	50X60X25X290X150	50	25	150	60	290	45	24	3/8”	22
ORK-ST0500250200	50X60X25X340X200	50	25	200	60	340	45	24	3/8”	22
ORK-ST0500250250	50X60X25X390X250	50	25	250	60	390	45	24	3/8”	22
ORK-ST0500250300	50X60X25X440X300	50	25	300	60	440	45	24	3/8”	22
ORK-ST0500250350	50X60X25X490X350	50	25	350	60	490	45	24	3/8”	22
ORK-ST0500250400	50X60X25X540X400	50	25	400	60	540	45	24	3/8”	22
ORK-ST0500250450	50X60X25X590X450	50	25	450	60	590	45	24	3/8”	22
ORK-ST0500250500	50X60X25X640X500	50	25	500	60	640	45	24	3/8”	22
ORK-ST0500250550	50X60X25X690X550	50	25	550	60	690	45	24	3/8”	22
ORK-ST0500250600	50X60X25X740X600	50	25	600	60	740	45	24	3/8”	22
ORK-ST0500250800	50X60X25X940X800	50	25	800	60	940	45	24	3/8”	22
ORK-ST0500251000	50X60X25X1140X1000	50	25	1000	60	1140	45	24	3/8”	22
ORK-ST0500300150	50X60X30X290X150	50	30	150	60	290	45	24	3/8”	22
ORK-ST0500300200	50X60X30X340X200	50	30	200	60	340	45	24	3/8”	22
ORK-ST0500300250	50X60X30X390X250	50	30	250	60	390	45	24	3/8”	22
ORK-ST0500300300	50X60X30X440X300	50	30	300	60	440	45	24	3/8”	22
ORK-ST0500300350	50X60X30X490X350	50	30	350	60	490	45	24	3/8”	22
ORK-ST0500300400	50X60X30X540X400	50	30	400	60	540	45	24	3/8”	22
ORK-ST0500300450	50X60X30X590X450	50	30	450	60	590	45	24	3/8”	22
ORK-ST0500300500	50X60X30X640X500	50	30	500	60	640	45	24	3/8”	22
ORK-ST0500300550	50X60X30X690X550	50	30	550	60	690	45	24	3/8”	22
ORK-ST0500300600	50X60X30X740X600	50	30	600	60	740	45	24	3/8”	22
ORK-ST0500300700	50X60X30X840X700	50	30	700	60	840	45	24	3/8”	22
ORK-ST0500300800	50X60X30X940X800	50	30	800	60	940	45	24	3/8”	22
ORK-ST0500301000	50X60X30X1140X1000	50	30	1000	60	1140	45	24	3/8”	22
ORK-ST0600300100	60X70X30X260X100	60	30	100	70	260	55	24,5	3/8”	23
ORK-ST0600300150	60X70X30X310X150	60	30	150	70	310	55	24,5	3/8”	23
ORK-ST0600300200	60X70X30X360X200	60	30	200	70	360	55	24,5	3/8”	23
ORK-ST0600300250	60X70X30X410X250	60	30	250	70	410	55	24,5	3/8”	23
ORK-ST0600300300	60X70X30X460X300	60	30	300	70	460	55	24,5	3/8”	23
ORK-ST0600300350	60X70X30X510X350	60	30	350	70	510	55	24,5	3/8”	23
ORK-ST0600300400	60X70X30X560X400	60	30	400	70	560	55	24,5	3/8”	23
ORK-ST0600300450	60X70X30X610X450	60	30	450	70	610	55	24,5	3/8”	23
ORK-ST0600300500	60X70X30X660X500	60	30	500	70	660	55	24,5	3/8”	23
ORK-ST0600300550	60X70X30X710X550	60	30	550	70	710	55	24,5	3/8”	23
ORK-ST0600300600	60X70X30X760X600	60	30	600	70	760	55	24,5	3/8”	23
ORK-ST0600300800	60X70X30X960X800	60	30	800	70	960	55	24,5	3/8”	23
ORK-ST0600301000	60X70X30X1160X1000	60	30	1000	70	1160	55	24,5	3/8”	23
ORK-ST0600350100	60X70X35X260X100	60	35	100	70	260	55	24,5	3/8”	23
ORK-ST0600350150	60X70X35X310X150	60	35	150	70	310	55	24,5	3/8”	23
ORK-ST0600350200	60X70X35X360X200	60	35	200	70	360	55	24,5	3/8”	23
ORK-ST0600350250	60X70X35X410X250	60	35	250	70	410	55	24,5	3/8”	23
ORK-ST0600350300	60X70X35X460X300	60	35	300	70	460	55	24,5	3/8”	23
ORK-ST0600350350	60X70X35X510X350	60	35	350	70	510	55	24,5	3/8”	23
ORK-ST0600350400	60X70X35X560X400	60	35	400	70	560	55	24,5	3/8”	23
ORK-ST0600350450	60X70X35X610X450	60	35	450	70	610	55	24,5	3/8”	23
ORK-ST0600350500	60X70X35X660X500	60	35	500	70	660	55	24,5	3/8”	23
ORK-ST0600350550	60X70X35X710X550	60	35	550	70	710	55	24,5	3/8”	23
ORK-ST0600350600	60X70X35X760X600	60	35	600	70	760	55	24,5	3/8”	23
ORK-ST0600350800	60X70X35X960X800	60	35	800	70	960	55	24,5	3/8”	23
ORK-ST0600351000	60X70X35X1160X1000	60	35	1000	70	1160	55	24,5	3/8”	23
ORK-ST0600400200	60X70X40X360X200	60	40	200	70	360	55	24,5	3/8”	23
ORK-ST0600400250	60X70X40X410X250	60	40	250	70	410	55	24,5	3/8”	23
ORK-ST0600400300	60X70X40X460X300	60	40	300	70	460	55	24,5	3/8”	23
ORK-ST0600400350	60X70X40X510X350	60	40	350	70	510	55	24,5	3/8”	23
ORK-ST0600400400	60X70X40X560X400	60	40	400	70	560	55	24,5	3/8”	23
ORK-ST0600400450	60X70X40X610X450	60	40	450	70	610	55	24,5	3/8”	23
ORK-ST0600400500	60X70X40X660X500	60	40	500	70	660	55	24,5	3/8”	23
ORK-ST0600400550	60X70X40X710X550	60	40	550	70	710	55	24,5	3/8”	23
ORK-ST0600400600	60X70X40X760X600	60	40	600	70	760	55	24,5	3/8”	23
ORK-ST0600400800	60X70X40X960X800	60	40	800	70	960	55	24,5	3/8”	23
ORK-ST0600401000	60X70X40X1160X1000	60	40	1000	70	1160	55	24,5	3/8”	23
ORK-ST0630400200	63X75X40X360X200	63	40	200	75	360	55	30	3/8”	23
ORK-ST0630400250	63X75X40X410X250	63	40	250	75	410	55	30	3/8”	23
ORK-ST0630400300	63X75X40X460X300	63	40	300	75	460	55	30	3/8”	23
ORK-ST0630400350	63X75X40X510X350	63	40	350	75	510	55	30	3/8”	23
ORK-ST0630400400	63X75X40X560X400	63	40	400	75	560	55	30	3/8”	23
ORK-ST0630400450	63X75X40X610X450	63	40	450	75	610	55	30	3/8”	23
ORK-ST0630400500	63X75X40X660X500	63	40	500	75	660	55	30	3/8”	23
ORK-ST0630400550	63X75X40X710X550	63	40	550	75	710	55	30	3/8”	23
ORK-ST0630400600	63X75X40X760X600	63	40	600	75	760	55	30	3/8”	23
ORK-ST0630400800	63X75X40X960X800	63	40	800	75	960	55	30	3/8”	23
ORK-ST0630401000	63X75X40X1160X1000	63	40	1000	75	1160	55	30	3/8”	23
ORK-ST0700350100	70X80X35X271X100	70	35	100	80	271	65	22	3/8”	34
ORK-ST0700350150	70X80X35X321X150	70	35	150	80	321	65	22	3/8”	34
ORK-ST0700350200	70X80X35X371X200	70	35	200	80	371	65	22	3/8”	34
ORK-ST0700350250	70X80X35X421X250	70	35	250	80	421	65	22	3/8”	34
ORK-ST0700350300	70X80X35X471X300	70	35	300	80	471	65	22	3/8”	34
ORK-ST0700350350	70X80X35X521X350	70	35	350	80	521	65	22	3/8”	34
ORK-ST0700350400	70X80X35X571X400	70	35	400	80	571	65	22	3/8”	34
ORK-ST0700350450	70X80X35X621X450	70	35	450	80	621	65	22	3/8”	34
ORK-ST0700350500	70X80X35X671X500	70	35	500	80	671	65	22	3/8”	34
ORK-ST0700350550	70X80X35X721X550	70	35	550	80	721	65	22	3/8”	34
ORK-ST0700350600	70X80X35X771X600	70	35	600	80	771	65	22	3/8”	34
ORK-ST0700350800	70X80X35X971X800	70	35	800	80	971	65	22	3/8”	34
ORK-ST0700351000	70X80X35X1171X1000	70	35	1000	80	1171	65	22	3/8”	34
ORK-ST0700400200	70X80X40X371X200	70	40	200	80	371	65	22	3/8”	34
ORK-ST0700400250	70X80X40X421X250	70	40	250	80	421	65	22	3/8”	34
ORK-ST0700400300	70X80X40X471X300	70	40	300	80	471	65	22	3/8”	34
ORK-ST0700400350	70X80X40X521X350	70	40	350	80	521	65	22	3/8”	34
ORK-ST0700400400	70X80X40X571X400	70	40	400	80	571	65	22	3/8”	34
ORK-ST0700400450	70X80X40X621X450	70	40	450	80	621	65	22	3/8”	34
ORK-ST0700400500	70X80X40X671X500	70	40	500	80	671	65	22	3/8”	34
ORK-ST0700400550	70X80X40X721X550	70	40	550	80	721	65	22	3/8”	34
ORK-ST0700400600	70X80X40X771X600	70	40	600	80	771	65	22	3/8”	34
ORK-ST0700400800	70X80X40X971X800	70	40	800	80	971	65	22	3/8”	34
ORK-ST0700401000	70X80X40X1171X1000	70	40	1000	80	1171	65	22	3/8”	34
ORK-ST0800400200	80X90X40X375X200	80	40	200	90	375	65	27	1/2”	25
ORK-ST0800400250	80X90X40X425X250	80	40	250	90	425	65	27	1/2”	25
ORK-ST0800400300	80X90X40X475X300	80	40	300	90	475	65	27	1/2”	25
ORK-ST0800400400	80X90X40X575X400	80	40	400	90	575	65	27	1/2”	25
ORK-ST0800400500	80X90X40X675X500	80	40	500	90	675	65	27	1/2”	25
ORK-ST0800400600	80X90X40X775X600	80	40	600	90	775	65	27	1/2”	25
ORK-ST0800400800	80X90X40X975X800	80	40	800	90	975	65	27	1/2”	25
ORK-ST0800401000	80X90X40X1175X1000	80	40	1000	90	1175	65	27	1/2”	25
ORK-ST0800500200	80X90X50X375X200	80	50	200	90	375	65	27	1/2”	25
ORK-ST0800500250	80X90X50X425X250	80	50	250	90	425	65	27	1/2”	25
ORK-ST0800500300	80X90X50X475X300	80	50	300	90	475	65	27	1/2”	25
ORK-ST0800500400	80X90X50X575X400	80	50	400	90	575	65	27	1/2”	25
ORK-ST0800500500	80X90X50X675X500	80	50	500	90	675	65	27	1/2”	25
ORK-ST0800500600	80X90X50X775X600	80	50	600	90	775	65	27	1/2”	25
ORK-ST0800500800	80X90X50X975X800	80	50	800	90	975	65	27	1/2”	25
ORK-ST0800501000	80X90X50X1175X1000	80	50	1000	90	1175	65	27	1/2”	25
ORK-ST0900500300	90X105X50X486X300	90	50	300	105	486	65	35	1/2”	23
ORK-ST0900500400	90X105X50X586X400	90	50	400	105	586	65	35	1/2”	23
ORK-ST0900500500	90X105X50X686X500	90	50	500	105	686	65	35	1/2”	23
ORK-ST0900500600	90X105X50X786X600	90	50	600	105	786	65	35	1/2”	23
ORK-ST0900500800	90X105X50X986X800	90	50	800	105	986	65	35	1/2”	23
ORK-ST0900501000	90X105X50X1186X1000	90	50	1000	105	1186	65	35	1/2”	23
ORK-ST1000500200	100X115X50X386X200	100	50	200	115	386	80	29	1/2”	21
ORK-ST1000500250	100X115X50X436X250	100	50	250	115	436	80	29	1/2”	21
ORK-ST1000500300	100X115X50X486X300	100	50	300	115	486	80	29	1/2”	21
ORK-ST1000500400	100X115X50X586X400	100	50	400	115	586	80	29	1/2”	21
ORK-ST1000500500	100X115X50X686X500	100	50	500	115	686	80	29	1/2”	21
ORK-ST1000500600	100X115X50X786X600	100	50	600	115	786	80	29	1/2”	21
ORK-ST1000500800	100X115X50X986X800	100	50	800	115	986	80	29	1/2”	21
ORK-ST1000501000	100X115X50X1186X1000	100	50	1000	115	1186	80	29	1/2”	21
ORK-ST1000600300	100X115X60X486X300	100	60	300	115	486	80	29	1/2”	21
ORK-ST1000600400	100X115X60X586X400	100	60	400	115	586	80	29	1/2”	21
ORK-ST1000600500	100X115X60X686X500	100	60	500	115	686	80	29	1/2”	21
ORK-ST1000600600	100X115X60X786X600	100	60	600	115	786	80	29	1/2”	21
ORK-ST1000600800	100X115X60X986X800	100	60	800	115	986	80	29	1/2”	21
ORK-ST1000601000	100X115X60X1186X1000	100	60	1000	115	1186	80	29	1/2”	21

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie HL 83

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	ØDF mm	E mm	F1	F2	G	S	ØJ	ØK	L
ORK-HL0250160050	25X32X16X32X160X50	25	16	50	32	32	160	25	25	3/8”	31	12.1	25	25
ORK-HL0250160100	25X32X16X32X210X100	25	16	100	32	32	210	25	25	3/8”	31	12.1	25	25
ORK-HL0250160150	25X32X16X32X260X150	25	16	150	32	32	260	25	25	3/8”	31	12.1	25	25
ORK-HL0250160200	25X32X16X32X310X200	25	16	200	32	32	310	25	25	3/8”	31	12.1	25	25
ORK-HL0320200050	32X40X20X40X205X50	32	20	50	40	40	205	40	33	3/8”	48	16.2	30	35
ORK-HL0320200100	32X40X20X40X255X100	32	20	100	40	40	255	40	33	3/8”	48	16.2	30	35
ORK-HL0320200150	32X40X20X40X305X150	32	20	150	40	40	305	40	33	3/8”	48	16.2	30	35
ORK-HL0320200200	32X40X20X40X355X200	32	20	200	40	40	355	40	33	3/8”	48	16.2	30	35
ORK-HL0320200250	32X40X20X40X405X250	32	20	250	40	40	405	40	33	3/8”	48	16.2	30	35
ORK-HL0320200300	32X40X20X40X455X300	32	20	300	40	40	455	40	33	3/8”	48	16.2	30	35
ORK-HL0320200400	32X40X20X40X555X400	32	20	400	40	40	555	40	33	3/8”	48	16.2	30	35
ORK-HL0320200500	32X40X20X40X655X500	32	20	500	40	40	655	40	33	3/8”	48	16.2	30	35
ORK-HL0400250100	40X50X25X50X270X100	40	25	100	50	50	270	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250150	40X50X25X50X320X150	40	25	150	50	50	320	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250200	40X50X25X50X370X200	40	25	200	50	50	370	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250250	40X50X25X50X420X250	40	25	250	50	50	420	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250300	40X50X25X50X470X300	40	25	300	50	50	470	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250400	40X50X25X50X570X400	40	25	400	50	50	570	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250500	40X50X25X50X670X500	40	25	500	50	50	670	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250600	40X50X25X50X770X600	40	25	600	50	50	770	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250700	40X50X25X50X870X700	40	25	700	50	50	870	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0400250800	40X50X25X50X970X800	40	25	800	50	50	970	40	56,5	3/8”	29,5	20,25	35	40
ORK-HL0500300100	50X60X30X60X300X100	50	30	100	60	60	300	45	50	3/8”	52	25,25	40	45
ORK-HL0500300150	50X60X30X60X350X150	50	30	150	60	60	350	45	50	3/8”	52	25,25	40	45
ORK-HL0500300200	50X60X30X60X400X200	50	30	200	60	60	400	45	50	3/8”	52	25,25	40	45
ORK-HL0500300250	50X60X30X60X450X250	50	30	250	60	60	450	45	50	3/8”	52	25,25	40	45
ORK-HL0500300300	50X60X30X60X500X300	50	30	300	60	60	500	45	50	3/8”	52	25,25	40	45
ORK-HL0500300400	50X60X30X60X600X400	50	30	400	60	60	600	45	50	3/8”	52	25,25	40	45
ORK-HL0500300500	50X60X30X60X700X500	50	30	500	60	60	700	45	50	3/8”	52	25,25	40	45
ORK-HL0500300600	50X60X30X60X800X600	50	30	600	60	60	800	45	50	3/8”	52	25,25	40	45
ORK-HL0500300700	50X60X30X60X900X700	50	30	700	60	60	900	45	50	3/8”	52	25,25	40	45
ORK-HL0500300800	50X60X30X60X1000X800	50	30	800	60	60	1000	45	50	3/8”	52	25,25	40	45
ORK-HL0500300900	50X60X30X60X1100X900	50	30	900	60	60	1100	45	50	3/8”	52	25,25	40	45
ORK-HL0500301000	50X60X30X60X1200X1000	50	30	1000	60	60	1200	45	50	3/8”	52	25,25	40	45
ORK-HL0600300100	60X70X30X70X300X100	60	30	100	70	70	300	57	58	3/8”	42	25,25	40	45
ORK-HL0600300150	60X70X30X70X350X150	60	30	150	70	70	350	57	58	3/8”	42	25,25	40	45
ORK-HL0600300200	60X70X30X70X400X200	60	30	200	70	70	400	57	58	3/8”	42	25,25	40	45
ORK-HL0600300250	60X70X30X70X450X250	60	30	250	70	70	450	57	58	3/8”	42	25,25	40	45
ORK-HL0600300300	60X70X30X70X500X300	60	30	300	70	70	500	57	58	3/8”	42	25,25	40	45
ORK-HL0600300350	60X70X30X70X550X350	60	30	350	70	70	550	57	58	3/8”	42	25,25	40	45
ORK-HL0600300400	60X70X30X70X600X400	60	30	400	70	70	600	57	58	3/8”	42	25,25	40	45
ORK-HL0600300450	60X70X30X70X650X450	60	30	450	70	70	650	57	58	3/8”	42	25,25	40	45
ORK-HL0600300500	60X70X30X70X700X500	60	30	500	70	70	700	57	58	3/8”	42	25,25	40	45
ORK-HL0600300600	60X70X30X70X800X600	60	30	600	70	70	800	57	58	3/8”	42	25,25	40	45
ORK-HL0600300700	60X70X30X70X900X700	60	30	700	70	70	900	57	58	3/8”	42	25,25	40	45
ORK-HL0600350200	60X70X35X70X400X200	60	35	200	70	70	400	57	58	3/8”	42	25,25	40	45
ORK-HL0600350300	60X70X35X70X500X300	60	35	300	70	70	500	57	58	3/8”	42	25,25	40	45
ORK-HL0600350400	60X70X35X70X600X400	60	35	400	70	70	600	57	58	3/8”	42	25,25	40	45
ORK-HL0600350500	60X70X35X70X700X500	60	35	500	70	70	700	57	58	3/8”	42	25,25	40	45
ORK-HL0600350600	60X70X35X70X800X600	60	35	600	70	70	800	57	58	3/8”	42	25,25	40	45
ORK-HL0600350700	60X70X35X70X900X700	60	35	700	70	70	900	57	58	3/8”	42	25,25	40	45
ORK-HL0600350800	60X70X35X70X1000X800	60	35	800	70	70	1000	57	58	3/8”	42	25,25	40	45
ORK-HL0600350900	60X70X35X70X1100X900	60	35	900	70	70	1100	57	58	3/8”	42	25,25	40	45
ORK-HL0600351000	60X70X35X70X1200X1000	60	35	1000	70	70	1200	57	58	3/8”	42	25,25	40	45
ORK-HL0700400200	70X80X40X80X410X200	70	40	200	80	80	410	65	47	3/8”	55	30,25	50	55
ORK-HL0700400250	70X80X40X80X460X250	70	40	250	80	80	460	65	47	3/8”	55	30,25	50	55
ORK-HL0700400300	70X80X40X80X510X300	70	40	300	80	80	510	65	47	3/8”	55	30,25	50	55
ORK-HL0700400350	70X80X40X80X560X350	70	40	350	80	80	560	65	47	3/8”	55	30,25	50	55
ORK-HL0700400400	70X80X40X80X610X400	70	40	400	80	80	610	65	47	3/8”	55	30,25	50	55
ORK-HL0700400450	70X80X40X80X660X450	70	40	450	80	80	660	65	47	3/8”	55	30,25	50	55
ORK-HL0700400500	70X80X40X80X710X500	70	40	500	80	80	710	65	47	3/8”	55	30,25	50	55
ORK-HL0700400600	70X80X40X80X810X600	70	40	600	80	80	810	65	47	3/8”	55	30,25	50	55
ORK-HL0700400700	70X80X40X80X910X700	70	40	700	80	80	910	65	47	3/8”	55	30,25	50	55
ORK-HL0700400800	70X80X40X80X1010X800	70	40	800	80	80	1010	65	47	3/8”	55	30,25	50	55
ORK-HL0700400900	70X80X40X80X1110X900	70	40	900	80	80	1110	65	47	3/8”	55	30,25	50	55
ORK-HL0800400200	80X90X40X90X410X200	80	40	200	90	90	410	65	51	1/2”	40	30,25	50	55
ORK-HL0800400250	80X90X40X90X460X250	80	40	250	90	90	460	65	51	1/2”	40	30,25	50	55
ORK-HL0800400300	80X90X40X90X510X300	80	40	300	90	90	510	65	51	1/2”	40	30,25	50	55
ORK-HL0800400350	80X90X40X90X560X350	80	40	350	90	90	560	65	51	1/2”	40	30,25	50	55
ORK-HL0800400400	80X90X40X90X610X400	80	40	400	90	90	610	65	51	1/2”	40	30,25	50	55
ORK-HL0800400500	80X90X40X90X710X500	80	40	500	90	90	710	65	51	1/2”	40	30,25	50	55
ORK-HL0800400600	80X90X40X90X810X600	80	40	600	90	90	810	65	51	1/2”	40	30,25	50	55
ORK-HL0800400700	80X90X40X90X910X700	80	40	700	90	90	910	65	51	1/2”	40	30,25	50	55
ORK-HL0800400800	80X90X40X90X1010X800	80	40	800	90	90	1010	65	51	1/2”	40	30,25	50	55
ORK-HL0800400900	80X90X40X90X1110X900	80	40	900	90	90	1110	65	51	1/2”	40	30,25	50	55
ORK-HL0800401000	80X90X40X90X1210X1000	80	40	1000	90	90	1210	65	51	1/2”	40	30,25	50	55
ORK-HL1000500200	100X115X50X115X430X200	100	50	200	115	115	430	82	51	1/2”	45	30,25	60	70
ORK-HL1000500300	100X115X50X115X530X300	100	50	300	115	115	530	82	51	1/2”	45	30,25	60	70
ORK-HL1000500400	100X115X50X115X630X400	100	50	400	115	115	630	82	51	1/2”	45	30,25	60	70
ORK-HL1000500500	100X115X50X115X730X500	100	50	500	115	115	730	82	51	1/2”	45	30,25	60	70
ORK-HL1000500700	100X115X50X115X930X700	100	50	700	115	115	930	82	51	1/2”	45	30,25	60	70
ORK-HL1000500900	100X115X50X115X1130X900	100	50	900	115	115	1130	82	51	1/2”	45	30,25	60	70
ORK-HL1000501000	100X115X50X115X1230X1000	100	50	1000	115	115	1230	82	51	1/2”	45	30,25	60	70

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie TB 162

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	ØJ	ØK	L1	L2	S
ORK-TB0320200050	32X40X20X200X50	32	20	50	40	200	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200100	32X40X20X250X100	32	20	100	40	250	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200150	32X40X20X300X150	32	20	150	40	300	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200200	32X40X20X350X200	32	20	200	40	350	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200250	32X40X20X400X250	32	20	250	40	400	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200300	32X40X20X450X300	32	20	300	40	450	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200400	32X40X20X550X400	32	20	400	40	550	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0320200500	32X40X20X650X500	32	20	500	40	650	38	20	3/8”	16,25	35	30	60	30,5
ORK-TB0400200100	40X50X20X265X100	40	20	100	50	265	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200150	40X50X20X315X150	40	20	150	50	315	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200200	40X50X20X365X200	40	20	200	50	365	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200250	40X50X20X415X250	40	20	250	50	415	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200300	40X50X20X465X300	40	20	300	50	465	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200350	40X50X20X515X350	40	20	350	50	515	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200400	40X50X20X565X400	40	20	400	50	565	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200450	40X50X20X615X450	40	20	450	50	615	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400200500	40X50X20X665X500	40	20	500	50	665	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250100	40X50X25X265X100	40	25	100	50	265	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250150	40X50X25X315X150	40	25	150	50	315	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250200	40X50X25X365X200	40	25	200	50	365	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250250	40X50X25X415X250	40	25	250	50	415	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250300	40X50X25X465X300	40	25	300	50	465	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250350	40X50X25X515X350	40	25	350	50	515	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250400	40X50X25X565X400	40	25	400	50	565	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250450	40X50X25X615X450	40	25	450	50	615	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250500	40X50X25X665X500	40	25	500	50	665	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250550	40X50X25X715X550	40	25	550	50	715	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0400250600	40X50X25X765X600	40	25	600	50	765	40	23	3/8”	16,25	35	30	60	39,5
ORK-TB0500250100	50X60X25X280X100	50	25	100	60	280	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250150	50X60X25X330X150	50	25	150	60	330	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250200	50X60X25X380X200	50	25	200	60	380	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250250	50X60X25X430X250	50	25	250	60	430	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250300	50X60X25X480X300	50	25	300	60	480	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250350	50X60X25X530X350	50	25	350	60	530	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250400	50X60X25X580X400	50	25	400	60	580	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250450	50X60X25X630X450	50	25	450	60	630	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250500	50X60X25X680X500	50	25	500	60	680	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250550	50X60X25X730X550	50	25	550	60	730	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250600	50X60X25X780X600	50	25	600	60	780	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500250800	50X60X25X980X800	50	25	800	60	980	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500251000	50X60X25X1180X1000	50	25	1000	60	1180	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300150	50X60X30X330X150	50	30	150	60	330	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300200	50X60X30X380X200	50	30	200	60	380	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300250	50X60X30X430X250	50	30	250	60	430	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300300	50X60X30X480X300	50	30	300	60	480	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300350	50X60X30X530X350	50	30	350	60	530	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300400	50X60X30X580X400	50	30	400	60	580	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300450	50X60X30X630X450	50	30	450	60	630	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300500	50X60X30X680X500	50	30	500	60	680	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300550	50X60X30X730X550	50	30	550	60	730	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300600	50X60X30X780X600	50	30	600	60	780	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300700	50X60X30X880X700	50	30	700	60	880	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500300800	50X60X30X980X800	50	30	800	60	980	43	26	3/8”	20,25	40	40	70	41
ORK-TB0500301000	50X60X30X1180X1000	50	30	1000	60	1180	43	26	3/8”	20,25	40	40	70	41
ORK-TB0600300100	60X70X30X310X100	60	30	100	70	310	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300150	60X70X30X360X150	60	30	150	70	360	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300200	60X70X30X410X200	60	30	200	70	410	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300250	60X70X30X460X250	60	30	250	70	460	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300300	60X70X30X510X300	60	30	300	70	510	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300350	60X70X30X560X350	60	30	350	70	560	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300400	60X70X30X610X400	60	30	400	70	610	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300450	60X70X30X660X450	60	30	450	70	660	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300500	60X70X30X710X500	60	30	500	70	710	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300550	60X70X30X760X550	60	30	550	70	760	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300600	60X70X30X810X600	60	30	600	70	810	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600300800	60X70X30X1010X800	60	30	800	70	1010	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600301000	60X70X30X1210X1000	60	30	1000	70	1210	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350100	60X70X35X310X100	60	35	100	70	310	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350150	60X70X35X360X150	60	35	150	70	360	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350200	60X70X35X410X200	60	35	200	70	410	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350250	60X70X35X460X250	60	35	250	70	460	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350300	60X70X35X510X300	60	35	300	70	510	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350350	60X70X35X560X350	60	35	350	70	560	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350400	60X70X35X610X400	60	35	400	70	610	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350450	60X70X35X660X450	60	35	450	70	660	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350500	60X70X35X710X500	60	35	500	70	710	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350550	60X70X35X760X550	60	35	550	70	760	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350600	60X70X35X810X600	60	35	600	70	810	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600350800	60X70X35X1010X800	60	35	800	70	1010	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600351000	60X70X35X1210X1000	60	35	1000	70	1210	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400200	60X70X40X410X200	60	40	200	70	410	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400250	60X70X40X460X250	60	40	250	70	460	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400300	60X70X40X510X300	60	40	300	70	510	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400350	60X70X40X560X350	60	40	350	70	560	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400400	60X70X40X610X400	60	40	400	70	610	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400450	60X70X40X660X450	60	40	450	70	660	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400500	60X70X40X710X500	60	40	500	70	710	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400550	60X70X40X760X550	60	40	550	70	760	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400600	60X70X40X810X600	60	40	600	70	810	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600400800	60X70X40X1010X800	60	40	800	70	1010	50	30	3/8”	25,25	50	50	80	48
ORK-TB0600401000	60X70X40X1210X1000	60	40	1000	70	1210	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400200	63X75X40X410X200	63	40	200	75	410	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400250	63X75X40X460X250	63	40	250	75	460	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400300	63X75X40X510X300	63	40	300	75	510	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400350	63X75X40X560X350	63	40	350	75	560	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400400	63X75X40X610X400	63	40	400	75	610	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400450	63X75X40X660X450	63	40	450	75	660	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400500	63X75X40X710X500	63	40	500	75	710	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400550	63X75X40X760X550	63	40	550	75	760	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400600	63X75X40X810X600	63	40	600	75	810	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630400800	63X75X40X1010X800	63	40	800	75	1010	50	30	3/8”	25,25	50	50	80	48
ORK-TB0630401000	63X75X40X1210X1000	63	40	1000	75	1210	50	30	3/8”	25,25	50	50	80	48
ORK-TB0700350100	70X80X35X310X100	70	35	100	80	310	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350150	70X80X35X360X150	70	35	150	80	360	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350200	70X80X35X410X200	70	35	200	80	410	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350250	70X80X35X460X250	70	35	250	80	460	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350300	70X80X35X510X300	70	35	300	80	510	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350350	70X80X35X560X350	70	35	350	80	560	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350400	70X80X35X610X400	70	35	400	80	610	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350450	70X80X35X660X450	70	35	450	80	660	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350500	70X80X35X710X500	70	35	500	80	710	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350550	70X80X35X760X550	70	35	550	80	760	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350600	70X80X35X810X600	70	35	600	80	810	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700350800	70X80X35X1010X800	70	35	800	80	1010	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700351000	70X80X35X1210X1000	70	35	1000	80	1210	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400200	70X80X40X410X200	70	40	200	80	410	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400250	70X80X40X460X250	70	40	250	80	460	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400300	70X80X40X510X300	70	40	300	80	510	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400350	70X80X40X560X350	70	40	350	80	560	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400400	70X80X40X610X400	70	40	400	80	610	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400450	70X80X40X660X450	70	40	450	80	660	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400500	70X80X40X710X500	70	40	500	80	710	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400550	70X80X40X760X550	70	40	550	80	760	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400600	70X80X40X810X600	70	40	600	80	810	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700400800	70X80X40X1010X800	70	40	800	80	1010	62	33	3/8”	25,25	50	50	80	48
ORK-TB0700401000	70X80X40X1210X1000	70	40	1000	80	1210	62	33	3/8”	25,25	50	50	80	48
ORK-TB0800400200	80X90X40X440X200	80	40	200	90	440	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800400250	80X90X40X490X250	80	40	250	90	490	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800400300	80X90X40X540X300	80	40	300	90	540	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800400400	80X90X40X640X400	80	40	400	90	640	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800400500	80X90X40X740X500	80	40	500	90	740	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800400600	80X90X40X840X600	80	40	600	90	840	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800400800	80X90X40X1040X800	80	40	800	90	1040	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800401000	80X90X40X1240X1000	80	40	1000	90	1240	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500200	80X90X50X440X200	80	50	200	90	440	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500250	80X90X50X490X250	80	50	250	90	490	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500300	80X90X50X540X300	80	50	300	90	540	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500400	80X90X50X640X400	80	50	400	90	640	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500500	80X90X50X740X500	80	50	500	90	740	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500600	80X90X50X840X600	80	50	600	90	840	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800500800	80X90X50X1040X800	80	50	800	90	1040	60	35	1/2”	30,25	60	60	110	55
ORK-TB0800501000	80X90X50X1240X1000	80	50	1000	90	1240	60	35	1/2”	30,25	60	60	110	55
ORK-TB0900500300	90X105X50X556X300	90	50	300	105	556	60	40	1/2”	40,25	70	70	130	58
ORK-TB0900500400	90X105X50X656X400	90	50	400	105	656	60	40	1/2”	40,25	70	70	130	58
ORK-TB0900500500	90X105X50X756X500	90	50	500	105	756	60	40	1/2”	40,25	70	70	130	58
ORK-TB0900500600	90X105X50X856X600	90	50	600	105	856	60	40	1/2”	40,25	70	70	130	58
ORK-TB0900500800	90X105X50X1056X800	90	50	800	105	1056	60	40	1/2”	40,25	70	70	130	58
ORK-TB0900501000	90X105X50X1256X1000	90	50	1000	105	1256	60	40	1/2”	40,25	70	70	130	58
ORK-TB1000500200	100X115X50X480X200	100	50	200	115	480	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000500250	100X115X50X530X250	100	50	250	115	530	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000500300	100X115X50X580X300	100	50	300	115	580	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000500400	100X115X50X680X400	100	50	400	115	680	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000500500	100X115X50X780X500	100	50	500	115	780	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000500600	100X115X50X880X600	100	50	600	115	880	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000500800	100X115X50X1080X800	100	50	800	115	1080	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000501000	100X115X50X1280X1000	100	50	1000	115	1280	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000600300	100X115X60X580X300	100	60	300	115	580	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000600400	100X115X60X680X400	100	60	400	115	680	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000600500	100X115X60X780X500	100	60	500	115	780	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000600600	100X115X60X880X600	100	60	600	115	880	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000600800	100X115X60X1080X800	100	60	800	115	1080	82	38	1/2”	40,25	70	70	130	60
ORK-TB1000601000	100X115X60X1280X1000	100	60	1000	115	1280	82	38	1/2”	40,25	70	70	130	60

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie TP 162

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	ØJ	K	L	Q	S
ORK-TP0320200050	32X40X20X290X50	32	20	50	40	290	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200100	32X40X20X340X100	32	20	100	40	340	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200150	32X40X20X390X150	32	20	150	40	390	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200200	32X40X20X440X200	32	20	200	40	440	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200250	32X40X20X490X250	32	20	250	40	490	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200300	32X40X20X540X300	32	20	300	40	540	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200400	32X40X20X640X400	32	20	400	40	640	40	24	3/8”	16,2	62	44	62	76
ORK-TP0320200500	32X40X20X740X500	32	20	500	40	740	40	24	3/8”	16,2	62	44	62	76
ORK-TP0400200100	40X50X20X350X100	40	20	100	50	350	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200150	40X50X20X400X150	40	20	150	50	400	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200200	40X50X20X450X200	40	20	200	50	450	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200250	40X50X20X500X250	40	20	250	50	500	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200300	40X50X20X550X300	40	20	300	50	550	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200350	40X50X20X600X350	40	20	350	50	600	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200400	40X50X20X650X400	40	20	400	50	650	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200450	40X50X20X700X450	40	20	450	50	700	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400200500	40X50X20X750X500	40	20	500	50	750	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250100	40X50X25X350X100	40	25	100	50	350	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250150	40X50X25X400X150	40	25	150	50	400	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250200	40X50X25X450X200	40	25	200	50	450	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250250	40X50X25X500X250	40	25	250	50	500	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250300	40X50X25X550X300	40	25	300	50	550	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250350	40X50X25X600X350	40	25	350	50	600	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250400	40X50X25X650X400	40	25	400	50	650	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250450	40X50X25X700X450	40	25	450	50	700	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250500	40X50X25X750X500	40	25	500	50	750	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250550	40X50X25X800X550	40	25	550	50	800	40	24	3/8”	16,2	62	44	62	80
ORK-TP0400250600	40X50X25X850X600	40	25	600	50	850	40	24	3/8”	16,2	62	44	62	80
ORK-TP0500250100	50X60X25X360X100	50	25	100	60	360	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250150	50X60X25X410X150	50	25	150	60	410	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250200	50X60X25X460X200	50	25	200	60	460	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250250	50X60X25X510X250	50	25	250	60	510	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250300	50X60X25X560X300	50	25	300	60	560	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250350	50X60X25X610X350	50	25	350	60	610	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250400	50X60X25X660X400	50	25	400	60	660	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250450	50X60X25X710X450	50	25	450	60	710	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250500	50X60X25X760X500	50	25	500	60	760	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250550	50X60X25X810X550	50	25	550	60	810	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250600	50X60X25X860X600	50	25	600	60	860	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500250800	50X60X25X1060X800	50	25	800	60	1060	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500251000	50X60X25X1260X1000	50	25	1000	60	1260	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300150	50X60X30X410X150	50	30	150	60	410	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300200	50X60X30X460X200	50	30	200	60	460	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300250	50X60X30X510X250	50	30	250	60	510	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300300	50X60X30X560X300	50	30	300	60	560	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300350	50X60X30X610X350	50	30	350	60	610	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300400	50X60X30X660X400	50	30	400	60	660	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300450	50X60X30X710X450	50	30	450	60	710	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300500	50X60X30X760X500	50	30	500	60	760	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300550	50X60X30X810X550	50	30	550	60	810	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300600	50X60X30X860X600	50	30	600	60	860	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300700	50X60X30X960X700	50	30	700	60	960	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500300800	50X60X30X1060X800	50	30	800	60	1060	45	20	3/8”	19,2	62	44	62	80
ORK-TP0500301000	50X60X30X1260X1000	50	30	1000	60	1260	45	20	3/8”	19,2	62	44	62	80
ORK-TP0600300100	60X70X30X390X100	60	30	100	70	390	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300150	60X70X30X440X150	60	30	150	70	440	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300200	60X70X30X490X200	60	30	200	70	490	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300250	60X70X30X540X250	60	30	250	70	540	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300300	60X70X30X590X300	60	30	300	70	590	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300350	60X70X30X640X350	60	30	350	70	640	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300400	60X70X30X690X400	60	30	400	70	690	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300450	60X70X30X740X450	60	30	450	70	740	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300500	60X70X30X790X500	60	30	500	70	790	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300550	60X70X30X840X550	60	30	550	70	840	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300600	60X70X30X890X600	60	30	600	70	890	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600300800	60X70X30X1090X800	60	30	800	70	1090	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600301000	60X70X30X1290X1000	60	30	1000	70	1290	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350100	60X70X35X390X100	60	35	100	70	390	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350150	60X70X35X440X150	60	35	150	70	440	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350200	60X70X35X490X200	60	35	200	70	490	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350250	60X70X35X540X250	60	35	250	70	540	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350300	60X70X35X590X300	60	35	300	70	590	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350350	60X70X35X640X350	60	35	350	70	640	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350400	60X70X35X690X400	60	35	400	70	690	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350450	60X70X35X740X450	60	35	450	70	740	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350500	60X70X35X790X500	60	35	500	70	790	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350550	60X70X35X840X550	60	35	550	70	840	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350600	60X70X35X890X600	60	35	600	70	890	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600350800	60X70X35X1090X800	60	35	800	70	1090	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600351000	60X70X35X1290X1000	60	35	1000	70	1290	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400200	60X70X40X490X200	60	40	200	70	490	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400250	60X70X40X540X250	60	40	250	70	540	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400300	60X70X40X590X300	60	40	300	70	590	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400350	60X70X40X640X350	60	40	350	70	640	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400400	60X70X40X690X400	60	40	400	70	690	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400450	60X70X40X740X450	60	40	450	70	740	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400500	60X70X40X790X500	60	40	500	70	790	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400550	60X70X40X840X550	60	40	550	70	840	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400600	60X70X40X890X600	60	40	600	70	890	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600400800	60X70X40X1090X800	60	40	800	70	1090	55	25	3/8”	25,4	75	51	65	88
ORK-TP0600401000	60X70X40X1290X1000	60	40	1000	70	1290	55	25	3/8”	25,4	75	51	65	88
ORK-TP0630400200	63X75X40X490X200	63	40	200	75	490	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400250	63X75X40X540X250	63	40	250	75	540	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400300	63X75X40X590X300	63	40	300	75	590	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400350	63X75X40X640X350	63	40	350	75	640	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400400	63X75X40X690X400	63	40	400	75	690	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400450	63X75X40X740X450	63	40	450	75	740	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400500	63X75X40X790X500	63	40	500	75	790	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400550	63X75X40X840X550	63	40	550	75	840	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400600	63X75X40X890X600	63	40	600	75	890	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630400800	63X75X40X1090X800	63	40	800	75	1090	55	30	3/8”	25,4	75	51	65	88
ORK-TP0630401000	63X75X40X1290X1000	63	40	1000	75	1290	55	30	3/8”	25,4	75	51	65	88
ORK-TP0700350100	70X80X35X390X100	70	35	100	80	390	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350150	70X80X35X440X150	70	35	150	80	440	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350200	70X80X35X490X200	70	35	200	80	490	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350250	70X80X35X540X250	70	35	250	80	540	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350300	70X80X35X590X300	70	35	300	80	590	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350350	70X80X35X640X350	70	35	350	80	640	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350400	70X80X35X690X400	70	35	400	80	690	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350450	70X80X35X740X450	70	35	450	80	740	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350500	70X80X35X790X500	70	35	500	80	790	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350550	70X80X35X840X550	70	35	550	80	840	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350600	70X80X35X890X600	70	35	600	80	890	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700350800	70X80X35X1090X800	70	35	800	80	1090	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700351000	70X80X35X1290X1000	70	35	1000	80	1290	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400200	70X80X40X490X200	70	40	200	80	490	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400250	70X80X40X540X250	70	40	250	80	540	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400300	70X80X40X590X300	70	40	300	80	590	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400350	70X80X40X640X350	70	40	350	80	640	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400400	70X80X40X690X400	70	40	400	80	690	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400450	70X80X40X740X450	70	40	450	80	740	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400500	70X80X40X790X500	70	40	500	80	790	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400550	70X80X40X840X550	70	40	550	80	840	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400600	70X80X40X890X600	70	40	600	80	890	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700400800	70X80X40X1090X800	70	40	800	80	1090	65	22	3/8”	25,4	75	51	65	88
ORK-TP0700401000	70X80X40X1290X1000	70	40	1000	80	1290	65	22	3/8”	25,4	75	51	65	88
ORK-TP0800400200	80X90X40X510X200	80	40	200	90	510	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800400250	80X90X40X560X250	80	40	250	90	560	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800400300	80X90X40X610X300	80	40	300	90	610	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800400400	80X90X40X710X400	80	40	400	90	710	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800400500	80X90X40X810X500	80	40	500	90	810	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800400600	80X90X40X910X600	80	40	600	90	910	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800400800	80X90X40X1110X800	80	40	800	90	1110	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800401000	80X90X40X1310X1000	80	40	1000	90	1310	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500200	80X90X50X510X200	80	50	200	90	510	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500250	80X90X50X560X250 H	80	50	250	90	560	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500300	80X90X50X610X300	80	50	300	90	610	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500400	80X90X50X710X400	80	50	400	90	710	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500500	80X90X50X810X500	80	50	500	90	810	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500600	80X90X50X910X600	80	50	600	90	910	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800500800	80X90X50X1110X800	80	50	800	90	1110	65	35	1/2”	32,4	85	51	65	90
ORK-TP0800501000	80X90X50X1310X1000	80	50	1000	90	1310	65	35	1/2”	32,4	85	51	65	90
ORK-TP0900500300	90X105X50X645X300	90	50	300	105	645	65	27	1/2”	40,2	105	75	85	108
ORK-TP0900500400	90X105X50X745X400	90	50	400	105	745	65	27	1/2”	40,2	105	75	85	108
ORK-TP0900500500	90X105X50X845X500	90	50	500	105	845	65	27	1/2”	40,2	105	75	85	108
ORK-TP0900500600	90X105X50X945X600	90	50	600	105	945	65	27	1/2”	40,2	105	75	85	108
ORK-TP0900500800	90X105X50X1145X800	90	50	800	105	1145	65	27	1/2”	40,2	105	75	85	108
ORK-TP0900501000	90X105X50X1345X1000	90	50	1000	105	1345	65	27	1/2”	40,2	105	75	85	108
ORK-TP1000500200	100X115X50X560X200	100	50	200	115	560	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000500250	100X115X50X610X250	100	50	250	115	610	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000500300	100X115X50X660X300	100	50	300	115	660	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000500400	100X115X50X760X400	100	50	400	115	760	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000500500	100X115X50X860X500	100	50	500	115	860	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000500600	100X115X50X960X600	100	50	600	115	960	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000500800	100X115X50X1160X800	100	50	800	115	1160	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000501000	100X115X50X1360X1000	100	50	1000	115	1360	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000600300	100X115X60X660X300	100	60	300	115	660	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000600400	100X115X60X760X400	100	60	400	115	760	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000600500	100X115X60X860X500	100	60	500	115	860	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000600600	100X115X60X960X600	100	60	600	115	960	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000600800	100X115X60X1160X800	100	60	800	115	1160	80	31	1/2”	40,2	105	75	85	110
ORK-TP1000601000	100X115X60X1360X1000	100	60	1000	115	1360	80	31	1/2”	40,2	105	75	85	110

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie PN 162

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	ØJ	K1	K2	L1	L2	Q	S
ORK-PN0320200050	32X40X20X239X50	32	20	50	40	239	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200100	32X40X20X289X100	32	20	100	40	289	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200150	32X40X20X339X150	32	20	150	40	339	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200200	32X40X20X389X200	32	20	200	40	389	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200250	32X40X20X439X250	32	20	250	40	439	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200300	32X40X20X489X300	32	20	300	40	489	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200400	32X40X20X589X400	32	20	400	40	589	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0320200500	32X40X20X689X500	32	20	500	40	689	40	20	3/8”	20	53	50	19	16	38	48
ORK-PN0400200100	40X50X20X300X100	40	20	100	50	300	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200150	40X50X20X350X150	40	20	150	50	350	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200200	40X50X20X400X200	40	20	200	50	400	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200250	40X50X20X450X250	40	20	250	50	450	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200300	40X50X20X500X300	40	20	300	50	500	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200350	40X50X20X550X350	40	20	350	50	550	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200400	40X50X20X600X400	40	20	400	50	600	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200450	40X50X20X650X450	40	20	450	50	650	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400200500	40X50X20X700X500	40	20	500	50	700	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250100	40X50X25X300X100	40	25	100	50	300	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250150	40X50X25X350X150	40	25	150	50	350	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250200	40X50X25X400X200	40	25	200	50	400	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250250	40X50X25X450X250	40	25	250	50	450	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250300	40X50X25X500X300	40	25	300	50	500	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250350	40X50X25X550X350	40	25	350	50	550	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250400	40X50X25X600X400	40	25	400	50	600	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250450	40X50X25X650X450	40	25	450	50	650	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250500	40X50X25X700X500	40	25	500	50	700	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250550	40X50X25X750X550	40	25	550	50	750	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0400250600	40X50X25X800X600	40	25	600	50	800	40	14	3/8”	20	53	50	19	16	38	54
ORK-PN0500250100	50X60X25X325X100	50	25	100	60	325	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250150	50X60X25X375X150	50	25	150	60	375	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250200	50X60X25X425X200	50	25	200	60	425	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250250	50X60X25X475X250	50	25	250	60	475	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250300	50X60X25X525X300	50	25	300	60	525	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250350	50X60X25X575X350	50	25	350	60	575	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250400	50X60X25X625X400	50	25	400	60	625	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250450	50X60X25X675X450	50	25	450	60	675	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250500	50X60X25X725X500	50	25	500	60	725	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250550	50X60X25X775X550	50	25	550	60	775	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250600	50X60X25X825X600	50	25	600	60	825	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500250800	50X60X25X1025X800	50	25	800	60	1025	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500251000	50X60X25X1225X1000	50	25	1000	60	1225	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300150	50X60X30X375X150	50	30	150	60	375	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300200	50X60X30X425X200	50	30	200	60	425	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300250	50X60X30X475X250	50	30	250	60	475	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300300	50X60X30X525X300	50	30	300	60	525	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300350	50X60X30X575X350	50	30	350	60	575	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300400	50X60X30X625X400	50	30	400	60	625	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300450	50X60X30X675X450	50	30	450	60	675	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300500	50X60X30X725X500	50	30	500	60	725	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300550	50X60X30X775X550	50	30	550	60	775	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300600	50X60X30X825X600	50	30	600	60	825	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300700	50X60X30X925X700	50	30	700	60	925	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500300800	50X60X30X1025X800	50	30	800	60	1025	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0500301000	50X60X30X1225X1000	50	30	1000	60	1225	45	26	3/8”	25	64	55	23	20	45	60
ORK-PN0600300100	60X70X30X350X100	60	30	100	70	350	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300150	60X70X30X400X150	60	30	150	70	400	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300200	60X70X30X450X200	60	30	200	70	450	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300250	60X70X30X500X250	60	30	250	70	500	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300300	60X70X30X550X300	60	30	300	70	550	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300350	60X70X30X600X350	60	30	350	70	600	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300400	60X70X30X650X400	60	30	400	70	650	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300450	60X70X30X700X450	60	30	450	70	700	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300500	60X70X30X750X500	60	30	500	70	750	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300550	60X70X30X800X550	60	30	550	70	800	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300600	60X70X30X850X600	60	30	600	70	850	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600300800	60X70X30X1050X800	60	30	800	70	1050	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600301000	60X70X30X1250X1000	60	30	1000	70	1250	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350100	60X70X35X350X100	60	35	100	70	350	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350150	60X70X35X400X150	60	35	150	70	400	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350200	60X70X35X450X200	60	35	200	70	450	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350250	60X70X35X500X250	60	35	250	70	500	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350300	60X70X35X550X300	60	35	300	70	550	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350350	60X70X35X600X350	60	35	350	70	600	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350400	60X70X35X650X400	60	35	400	70	650	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350450	60X70X35X700X450	60	35	450	70	700	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350500	60X70X35X750X500	60	35	500	70	750	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350550	60X70X35X800X550	60	35	550	70	800	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350600	60X70X35X850X600	60	35	600	70	850	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600350800	60X70X35X1050X800	60	35	800	70	1050	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600351000	60X70X35X1250X1000	60	35	1000	70	1250	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400200	60X70X40X450X200	60	40	200	70	450	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400250	60X70X40X500X250	60	40	250	70	500	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400300	60X70X40X550X300	60	40	300	70	550	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400350	60X70X40X600X350	60	40	350	70	600	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400400	60X70X40X650X400	60	40	400	70	650	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400450	60X70X40X700X450	60	40	450	70	700	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400500	60X70X40X750X500	60	40	500	70	750	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400550	60X70X40X800X550	60	40	550	70	800	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400600	60X70X40X850X600	60	40	600	70	850	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600400800	60X70X40X1050X800	60	40	800	70	1050	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0600401000	60X70X40X1250X1000	60	40	1000	70	1250	55	30	3/8”	30	73	65	28	22	51	69
ORK-PN0630400200	63X75X40X450X200	63	40	200	75	450	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400250	63X75X40X500X250	63	40	250	75	500	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400300	63X75X40X550X300	63	40	300	75	550	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400350	63X75X40X600X350	63	40	350	75	600	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400400	63X75X40X650X400	63	40	400	75	650	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400450	63X75X40X700X450	63	40	450	75	700	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400500	63X75X40X750X500	63	40	500	75	750	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400550	63X75X40X800X550 HİDROLİK SİLİNDİR	63	40	550	75	800	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400600	63X75X40X850X600	63	40	600	75	850	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630400800	63X75X40X1050X800	63	40	800	75	1050	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0630401000	63X75X40X1250X1000	63	40	1000	75	1250	55	30	3/8”	30	73	65	28	22	51	64
ORK-PN0700350100	70X80X35X350X100	70	35	100	80	350	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350150	70X80X35X400X150	70	35	150	80	400	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350200	70X80X35X450X200	70	35	200	80	450	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350250	70X80X35X500X250	70	35	250	80	500	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350300	70X80X35X550X300	70	35	300	80	550	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350350	70X80X35X600X350	70	35	350	80	600	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350400	70X80X35X650X400	70	35	400	80	650	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350450	70X80X35X700X450	70	35	450	80	700	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350500	70X80X35X750X500	70	35	500	80	750	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350550	70X80X35X800X550	70	35	550	80	800	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350600	70X80X35X850X600	70	35	600	80	850	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700350800	70X80X35X1050X800	70	35	800	80	1050	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700351000	70X80X35X1250X1000	70	35	1000	80	1250	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400200	70X80X40X450X200	70	40	200	80	450	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400250	70X80X40X500X250	70	40	250	80	500	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400300	70X80X40X550X300	70	40	300	80	550	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400350	70X80X40X600X350	70	40	350	80	600	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400400	70X80X40X650X400	70	40	400	80	650	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400450	70X80X40X700X450	70	40	450	80	700	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400500	70X80X40X750X500	70	40	500	80	750	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400550	70X80X40X800X550	70	40	550	80	800	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400600	70X80X40X850X600	70	40	600	80	850	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700400800	70X80X40X1050X800	70	40	800	80	1050	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0700401000	70X80X40X1250X1000	70	40	1000	80	1250	65	22	3/8”	30	73	65	28	22	51	67
ORK-PN0800400200	80X90X40X485X200	80	40	200	90	485	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800400250	80X90X40X535X250	80	40	250	90	535	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800400300	80X90X40X585X300	80	40	300	90	585	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800400400	80X90X40X685X400	80	40	400	90	685	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800400500	80X90X40X785X500	80	40	500	90	785	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800400600	80X90X40X885X600	80	40	600	90	885	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800400800	80X90X40X1085X800	80	40	800	90	1085	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800401000	80X90X40X1285X1000	80	40	1000	90	1285	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500200	80X90X50X485X200	80	50	200	90	485	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500250	80X90X50X535X250	80	50	250	90	535	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500300	80X90X50X585X300	80	50	300	90	585	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500400	80X90X50X685X400	80	50	400	90	685	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500500	80X90X50X785X500	80	50	500	90	785	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500600	80X90X50X885X600	80	50	600	90	885	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800500800	80X90X50X1085X800	80	50	800	90	1085	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0800501000	80X90X50X1285X1000	80	50	1000	90	1285	65	25	1/2”	35	82	83	30	25	61	79
ORK-PN0900500300	90X105X50X620X300	90	50	300	105	620	65	27	1/2”	40	92	100	35	28	69	99
ORK-PN0900500400	90X105X50X720X400	90	50	400	105	720	65	27	1/2”	40	92	100	35	28	69	99
ORK-PN0900500500	90X105X50X820X500	90	50	500	105	820	65	27	1/2”	40	92	100	35	28	69	99
ORK-PN0900500600	90X105X50X920X600	90	50	600	105	920	65	27	1/2”	40	92	100	35	28	69	99
ORK-PN0900500800	90X105X50X1120X800	90	50	800	105	1120	65	27	1/2”	40	92	100	35	28	69	99
ORK-PN0900501000	90X105X50X1320X1000	90	50	1000	105	1320	65	27	1/2”	40	92	100	35	28	69	99
ORK-PN1000500200	100X115X50X540X200	100	50	200	115	540	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000500250	100X115X50X590X250	100	50	250	115	590	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000500300	100X115X50X640X300	100	50	300	115	640	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000500400	100X115X50X740X400	100	50	400	115	740	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000500500	100X115X50X840X500	100	50	500	115	840	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000500600	100X115X50X940X600	100	50	600	115	940	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000500800	100X115X50X1140X800	100	50	800	115	1140	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000501000	100X115X50X1340X1000	100	50	1000	115	1340	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000600300	100X115X60X640X300	100	60	300	115	640	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000600400	100X115X60X740X400	100	60	400	115	740	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000600500	100X115X60X840X500	100	60	500	115	840	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000600600	100X115X60X940X600	100	60	600	115	940	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000600800	100X115X60X1140X800	100	60	800	115	1140	82	38	1/2”	40	92	100	35	28	69	96
ORK-PN1000601000	100X115X60X1340X1000	100	60	1000	115	1340	82	38	1/2”	40	92	100	35	28	69	96

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie CT 162

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	ØJ	ØK	L	S
ORK-CT0320200050	32X40X20X200X50	32	20	50	40	200	38	20	3/8”	15	40	12	25
ORK-CT0320200100	32X40X20X250X100	32	20	100	40	250	38	20	3/8”	15	40	12	25
ORK-CT0320200150	32X40X20X300X150	32	20	150	40	300	38	20	3/8”	15	40	12	25
ORK-CT0320200200	32X40X20X350X200	32	20	200	40	350	38	20	3/8”	15	40	12	25
ORK-CT0320200250	32X40X20X400X250	32	20	250	40	400	38	20	3/8”	15	40	12	25
ORK-CT0320200300	32X40X20X450X300	32	20	300	40	450	38	20	3/8”	15	40	12	25
ORK-CT0320200400	32X40X20X550X400	32	20	400	40	550	38	20	3/8”	15	40	12	25
ORK-CT0320200500	32X40X20X650X500	32	20	500	40	650	38	20	3/8”	15	40	12	25
ORK-CT0400200100	40X50X20X280X100	40	20	100	50	280	40	23	3/8”	20	50	16	47
ORK-CT0400200150	40X50X20X330X150	40	20	150	50	330	40	23	3/8”	20	50	16	47
ORK-CT0400200200	40X50X20X380X200	40	20	200	50	380	40	23	3/8”	20	50	16	47
ORK-CT0400200250	40X50X20X430X250	40	20	250	50	430	40	23	3/8”	20	50	16	47
ORK-CT0400200300	40X50X20X480X300	40	20	300	50	480	40	23	3/8”	20	50	16	47
ORK-CT0400200350	40X50X20X530X350	40	20	350	50	530	40	23	3/8”	20	50	16	47
ORK-CT0400200400	40X50X20X580X400	40	20	400	50	580	40	23	3/8”	20	50	16	47
ORK-CT0400200450	40X50X20X630X450	40	20	450	50	630	40	23	3/8”	20	50	16	47
ORK-CT0400200500	40X50X20X680X500	40	20	500	50	680	40	23	3/8”	20	50	16	47
ORK-CT0400250100	40X50X25X280X100	40	25	100	50	280	40	23	3/8”	20	50	16	47
ORK-CT0400250150	40X50X25X330X150	40	25	150	50	330	40	23	3/8”	20	50	16	47
ORK-CT0400250200	40X50X25X380X200	40	25	200	50	380	40	23	3/8”	20	50	16	47
ORK-CT0400250250	40X50X25X430X250	40	25	250	50	430	40	23	3/8”	20	50	16	47
ORK-CT0400250300	40X50X25X480X300	40	25	300	50	480	40	23	3/8”	20	50	16	47
ORK-CT0400250350	40X50X25X530X350	40	25	350	50	530	40	23	3/8”	20	50	16	47
ORK-CT0400250400	40X50X25X580X400	40	25	400	50	580	40	23	3/8”	20	50	16	47
ORK-CT0400250450	40X50X25X630X450	40	25	450	50	630	40	23	3/8”	20	50	16	47
ORK-CT0400250500	40X50X25X680X500	40	25	500	50	680	40	23	3/8”	20	50	16	47
ORK-CT0400250550	40X50X25X730X550	40	25	550	50	730	40	23	3/8”	20	50	16	47
ORK-CT0400250600	40X50X25X780X600	40	25	600	50	780	40	23	3/8”	20	50	16	47
ORK-CT0500250100	50X60X25X310X100	50	25	100	60	310	43	26	3/8”	25	69	20	55,5
ORK-CT0500250150	50X60X25X360X150	50	25	150	60	360	43	26	3/8”	25	69	20	55,5
ORK-CT0500250200	50X60X25X410X200	50	25	200	60	410	43	26	3/8”	25	69	20	55,5
ORK-CT0500250250	50X60X25X460X250	50	25	250	60	460	43	26	3/8”	25	69	20	55,5
ORK-CT0500250300	50X60X25X510X300	50	25	300	60	510	43	26	3/8”	25	69	20	55,5
ORK-CT0500250350	50X60X25X560X350	50	25	350	60	560	43	26	3/8”	25	69	20	55,5
ORK-CT0500250400	50X60X25X610X400	50	25	400	60	610	43	26	3/8”	25	69	20	55,5
ORK-CT0500250450	50X60X25X660X450	50	25	450	60	660	43	26	3/8”	25	69	20	55,5
ORK-CT0500250500	50X60X25X710X500	50	25	500	60	710	43	26	3/8”	25	69	20	55,5
ORK-CT0500250550	50X60X25X760X550	50	25	550	60	760	43	26	3/8”	25	69	20	55,5
ORK-CT0500250600	50X60X25X810X600	50	25	600	60	810	43	26	3/8”	25	69	20	55,5
ORK-CT0500250800	50X60X25X1010X800	50	25	800	60	1010	43	26	3/8”	25	69	20	55,5
ORK-CT0500251000	50X60X25X1210X1000	50	25	1000	60	1210	43	26	3/8”	25	69	20	55,5
ORK-CT0500300150	50X60X30X360X150	50	30	150	60	360	43	26	3/8”	25	69	20	55,5
ORK-CT0500300200	50X60X30X410X200	50	30	200	60	410	43	26	3/8”	25	69	20	55,5
ORK-CT0500300250	50X60X30X460X250	50	30	250	60	460	43	26	3/8”	25	69	20	55,5
ORK-CT0500300300	50X60X30X510X300	50	30	300	60	510	43	26	3/8”	25	69	20	55,5
ORK-CT0500300350	50X60X30X560X350	50	30	350	60	560	43	26	3/8”	25	69	20	55,5
ORK-CT0500300400	50X60X30X610X400	50	30	400	60	610	43	26	3/8”	25	69	20	55,5
ORK-CT0500300450	50X60X30X660X450	50	30	450	60	660	43	26	3/8”	25	69	20	55,5
ORK-CT0500300500	50X60X30X710X500	50	30	500	60	710	43	26	3/8”	25	69	20	55,5
ORK-CT0500300550	50X60X30X760X550	50	30	550	60	760	43	26	3/8”	25	69	20	55,5
ORK-CT0500300600	50X60X30X810X600	50	30	600	60	810	43	26	3/8”	25	69	20	55,5
ORK-CT0500300700	50X60X30X910X700	50	30	700	60	910	43	26	3/8”	25	69	20	55,5
ORK-CT0500300800	50X60X30X1010X800	50	30	800	60	1010	43	26	3/8”	25	69	20	55,5
ORK-CT0500301000	50X60X30X1210X1000	50	30	1000	60	1210	43	26	3/8”	25	69	20	55,5
ORK-CT0600300100	60X70X30X329X100	60	30	100	70	329	50	30	3/8”	25	69	20	57,5
ORK-CT0600300150	60X70X30X379X150	60	30	150	70	379	50	30	3/8”	25	69	20	57,5
ORK-CT0600300200	60X70X30X429X200	60	30	200	70	429	50	30	3/8”	25	69	20	57,5
ORK-CT0600300250	60X70X30X479X250	60	30	250	70	479	50	30	3/8”	25	69	20	57,5
ORK-CT0600300300	60X70X30X529X300	60	30	300	70	529	50	30	3/8”	25	69	20	57,5
ORK-CT0600300350	60X70X30X579X350	60	30	350	70	579	50	30	3/8”	25	69	20	57,5
ORK-CT0600300400	60X70X30X629X400	60	30	400	70	629	50	30	3/8”	25	69	20	57,5
ORK-CT0600300450	60X70X30X679X450	60	30	450	70	679	50	30	3/8”	25	69	20	57,5
ORK-CT0600300500	60X70X30X729X500	60	30	500	70	729	50	30	3/8”	25	69	20	57,5
ORK-CT0600300550	60X70X30X779X550	60	30	550	70	779	50	30	3/8”	25	69	20	57,5
ORK-CT0600300600	60X70X30X829X600	60	30	600	70	829	50	30	3/8”	25	69	20	57,5
ORK-CT0600300800	60X70X30X1029X800	60	30	800	70	1029	50	30	3/8”	25	69	20	57,5
ORK-CT0600301000	60X70X30X1229X1000	60	30	1000	70	1229	50	30	3/8”	25	69	20	57,5
ORK-CT0600350100	60X70X35X329X100	60	35	100	70	329	50	30	3/8”	25	69	20	57,5
ORK-CT0600350150	60X70X35X379X150	60	35	150	70	379	50	30	3/8”	25	69	20	57,5
ORK-CT0600350200	60X70X35X429X200	60	35	200	70	429	50	30	3/8”	25	69	20	57,5
ORK-CT0600350250	60X70X35X479X250	60	35	250	70	479	50	30	3/8”	25	69	20	57,5
ORK-CT0600350300	60X70X35X529X300	60	35	300	70	529	50	30	3/8”	25	69	20	57,5
ORK-CT0600350350	60X70X35X579X350	60	35	350	70	579	50	30	3/8”	25	69	20	57,5
ORK-CT0600350400	60X70X35X629X400	60	35	400	70	629	50	30	3/8”	25	69	20	57,5
ORK-CT0600350450	60X70X35X679X450	60	35	450	70	679	50	30	3/8”	25	69	20	57,5
ORK-CT0600350500	60X70X35X729X500	60	35	500	70	729	50	30	3/8”	25	69	20	57,5
ORK-CT0600350550	60X70X35X779X550	60	35	550	70	779	50	30	3/8”	25	69	20	57,5
ORK-CT0600350600	60X70X35X829X600	60	35	600	70	829	50	30	3/8”	25	69	20	57,5
ORK-CT0600350800	60X70X35X1029X800	60	35	800	70	1029	50	30	3/8”	25	69	20	57,5
ORK-CT0600351000	60X70X35X1229X1000	60	35	1000	70	1229	50	30	3/8”	25	69	20	57,5
ORK-CT0600400200	60X70X40X429X200	60	40	200	70	429	50	30	3/8”	25	69	20	57,5
ORK-CT0600400250	60X70X40X479X250	60	40	250	70	479	50	30	3/8”	25	69	20	57,5
ORK-CT0600400300	60X70X40X529X300	60	40	300	70	529	50	30	3/8”	25	69	20	57,5
ORK-CT0600400350	60X70X40X579X350	60	40	350	70	579	50	30	3/8”	25	69	20	57,5
ORK-CT0600400400	60X70X40X629X400	60	40	400	70	629	50	30	3/8”	25	69	20	57,5
ORK-CT0600400450	60X70X40X679X450	60	40	450	70	679	50	30	3/8”	25	69	20	57,5
ORK-CT0600400500	60X70X40X729X500	60	40	500	70	729	50	30	3/8”	25	69	20	57,5
ORK-CT0600400550	60X70X40X779X550	60	40	550	70	779	50	30	3/8”	25	69	20	57,5
ORK-CT0600400600	60X70X40X829X600	60	40	600	70	829	50	30	3/8”	25	69	20	57,5
ORK-CT0600400800	60X70X40X1029X800	60	40	800	70	1029	50	30	3/8”	25	69	20	57,5
ORK-CT0600401000	60X70X40X1229X1000	60	40	1000	70	1229	50	30	3/8”	25	69	20	57,5
ORK-CT0630400200	63X75X40X429X200	63	40	200	75	429	50	30	3/8”	25	69	20	57,5
ORK-CT0630400250	63X75X40X479X250	63	40	250	75	479	50	30	3/8”	25	69	20	57,5
ORK-CT0630400300	63X75X40X529X300	63	40	300	75	529	50	30	3/8”	25	69	20	57,5
ORK-CT0630400350	63X75X40X579X350	63	40	350	75	579	50	30	3/8”	25	69	20	57,5
ORK-CT0630400400	63X75X40X629X400	63	40	400	75	629	50	30	3/8”	25	69	20	57,5
ORK-CT0630400450	63X75X40X679X450	63	40	450	75	679	50	30	3/8”	25	69	20	57,5
ORK-CT0630400500	63X75X40X729X500	63	40	500	75	729	50	30	3/8”	25	69	20	57,5
ORK-CT0630400550	63X75X40X779X550	63	40	550	75	779	50	30	3/8”	25	69	20	57,5
ORK-CT0630400600	63X75X40X829X600	63	40	600	75	829	50	30	3/8”	25	69	20	57,5
ORK-CT0630400800	63X75X40X1029X800	63	40	800	75	1029	50	30	3/8”	25	69	20	57,5
ORK-CT0630401000	63X75X40X1229X1000	63	40	1000	75	1229	50	30	3/8”	25	69	20	57,5
ORK-CT0700350100	70X80X35X335X100	70	35	100	80	335	62	33	3/8”	30	75	22	60,5
ORK-CT0700350150	70X80X35X385X150	70	35	150	80	385	62	33	3/8”	30	75	22	60,5
ORK-CT0700350200	70X80X35X435X200	70	35	200	80	435	62	33	3/8”	30	75	22	60,5
ORK-CT0700350250	70X80X35X485X250	70	35	250	80	485	62	33	3/8”	30	75	22	60,5
ORK-CT0700350300	70X80X35X535X300	70	35	300	80	535	62	33	3/8”	30	75	22	60,5
ORK-CT0700350350	70X80X35X585X350	70	35	350	80	585	62	33	3/8”	30	75	22	60,5
ORK-CT0700350400	70X80X35X635X400	70	35	400	80	635	62	33	3/8”	30	75	22	60,5
ORK-CT0700350450	70X80X35X685X450	70	35	450	80	685	62	33	3/8”	30	75	22	60,5
ORK-CT0700350500	70X80X35X735X500	70	35	500	80	735	62	33	3/8”	30	75	22	60,5
ORK-CT0700350550	70X80X35X785X550	70	35	550	80	785	62	33	3/8”	30	75	22	60,5
ORK-CT0700350600	70X80X35X835X600	70	35	600	80	835	62	33	3/8”	30	75	22	60,5
ORK-CT0700350800	70X80X35X1035X800	70	35	800	80	1035	62	33	3/8”	30	75	22	60,5
ORK-CT0700351000	70X80X35X1235X1000	70	35	1000	80	1235	62	33	3/8”	30	75	22	60,5
ORK-CT0700400200	70X80X40X435X200	70	40	200	80	435	62	33	3/8”	30	75	22	60,5
ORK-CT0700400250	70X80X40X485X250	70	40	250	80	485	62	33	3/8”	30	75	22	60,5
ORK-CT0700400300	70X80X40X535X300	70	40	300	80	535	62	33	3/8”	30	75	22	60,5
ORK-CT0700400350	70X80X40X585X350	70	40	350	80	585	62	33	3/8”	30	75	22	60,5
ORK-CT0700400400	70X80X40X635X400	70	40	400	80	635	62	33	3/8”	30	75	22	60,5
ORK-CT0700400450	70X80X40X685X450	70	40	450	80	685	62	33	3/8”	30	75	22	60,5
ORK-CT0700400500	70X80X40X735X500	70	40	500	80	735	62	33	3/8”	30	75	22	60,5
ORK-CT0700400550	70X80X40X785X550	70	40	550	80	785	62	33	3/8”	30	75	22	60,5
ORK-CT0700400600	70X80X40X835X600	70	40	600	80	835	62	33	3/8”	30	75	22	60,5
ORK-CT0700400800	70X80X40X1035X800	70	40	800	80	1035	62	33	3/8”	30	75	22	60,5
ORK-CT0700401000	70X80X40X1235X1000	70	40	1000	80	1235	62	33	3/8”	30	75	22	60,5
ORK-CT0800400200	80X90X40X474X200	80	40	200	90	474	60	35	1/2”	40	94	28	72
ORK-CT0800400250	80X90X40X524X250	80	40	250	90	524	60	35	1/2”	40	94	28	72
ORK-CT0800400300	80X90X40X574X300	80	40	300	90	574	60	35	1/2”	40	94	28	72
ORK-CT0800400400	80X90X40X674X400	80	40	400	90	674	60	35	1/2”	40	94	28	72
ORK-CT0800400500	80X90X40X774X500	80	40	500	90	774	60	35	1/2”	40	94	28	72
ORK-CT0800400600	80X90X40X874X600	80	40	600	90	874	60	35	1/2”	40	94	28	72
ORK-CT0800400800	80X90X40X1074X800	80	40	800	90	1074	60	35	1/2”	40	94	28	72
ORK-CT0800401000	80X90X40X1274X1000	80	40	1000	90	1274	60	35	1/2”	40	94	28	72
ORK-CT0800500200	80X90X50X474X200	80	50	200	90	474	60	35	1/2”	40	94	28	72
ORK-CT0800500250	80X90X50X524X250	80	50	250	90	524	60	35	1/2”	40	94	28	72
ORK-CT0800500300	80X90X50X574X300	80	50	300	90	574	60	35	1/2”	40	94	28	72
ORK-CT0800500400	80X90X50X674X400	80	50	400	90	674	60	35	1/2”	40	94	28	72
ORK-CT0800500500	80X90X50X774X500	80	50	500	90	774	60	35	1/2”	40	94	28	72
ORK-CT0800500600	80X90X50X874X600	80	50	600	90	874	60	35	1/2”	40	94	28	72
ORK-CT0800500800	80X90X50X1074X800	80	50	800	90	1074	60	35	1/2”	40	94	28	72
ORK-CT0800501000	80X90X50X1274X1000	80	50	1000	90	1274	60	35	1/2”	40	94	28	72
ORK-CT0900500300	90X105X50X580X300	90	50	300	105	580	60	40	1/2”	40	94	28	70
ORK-CT0900500400	90X105X50X680X400	90	50	400	105	680	60	40	1/2”	40	94	28	70
ORK-CT0900500500	90X105X50X780X500	90	50	500	105	780	60	40	1/2”	40	94	28	70
ORK-CT0900500600	90X105X50X880X600	90	50	600	105	880	60	40	1/2”	40	94	28	70
ORK-CT0900500800	90X105X50X1080X800	90	50	800	105	1080	60	40	1/2”	40	94	28	70
ORK-CT0900501000	90X105X50X1280X1000	90	50	1000	105	1280	60	40	1/2”	40	94	28	70
ORK-CT1000500200	100X115X50X530X200	100	50	200	115	530	82	38	1/2”	50	120	40	85
ORK-CT1000500250	100X115X50X580X250	100	50	250	115	580	82	38	1/2”	50	120	40	85
ORK-CT1000500300	100X115X50X630X300	100	50	300	115	630	82	38	1/2”	50	120	40	85
ORK-CT1000500400	100X115X50X730X400	100	50	400	115	730	82	38	1/2”	50	120	40	85
ORK-CT1000500500	100X115X50X830X500	100	50	500	115	830	82	38	1/2”	50	120	40	85
ORK-CT1000500600	100X115X50X930X600	100	50	600	115	930	82	38	1/2”	50	120	40	85
ORK-CT1000500800	100X115X50X1130X800	100	50	800	115	1130	82	38	1/2”	50	120	40	85
ORK-CT1000501000	100X115X50X1330X1000	100	50	1000	115	1330	82	38	1/2”	50	120	40	85
ORK-CT1000600300	100X115X60X630X300	100	60	300	115	630	82	38	1/2”	50	120	40	85
ORK-CT1000600400	100X115X60X730X400	100	60	400	115	730	82	38	1/2”	50	120	40	85
ORK-CT1000600500	100X115X60X830X500	100	60	500	115	830	82	38	1/2”	50	120	40	85
ORK-CT1000600600	100X115X60X930X600	100	60	600	115	930	82	38	1/2”	50	120	40	85
ORK-CT1000600800	100X115X60X1130X800	100	60	800	115	1130	82	38	1/2”	50	120	40	85
ORK-CT1000601000	100X115X60X1330X1000	100	60	1000	115	1330	82	38	1/2”	50	120	40	85

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie FR 162

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	ØJ	K	L1	L2	Q1	Q2	R	S
ORK-FR0320200050	32X40X20X226X50	32	20	50	40	226	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200100	32X40X20X276X100	32	20	100	40	276	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200150	32X40X20X326X150	32	20	150	40	326	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200200	32X40X20X376X200	32	20	200	40	376	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200250	32X40X20X426X250	32	20	250	40	426	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200300	32X40X20X476X300	32	20	300	40	476	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200400	32X40X20X576X400	32	20	400	40	576	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0320200500	32X40X20X676X500	32	20	500	40	676	38	20	3/8”	16,2	35	20	35	34	25	16	49
ORK-FR0400200100	40X50X20X289X100	40	20	100	50	289	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200150	40X50X20X339X150	40	20	150	50	339	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200200	40X50X20X389X200	40	20	200	50	389	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200250	40X50X20X439X250	40	20	250	50	439	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200300	40X50X20X489X300	40	20	300	50	489	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200350	40X50X20X539X350	40	20	350	50	539	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200400	40X50X20X589X400	40	20	400	50	589	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200450	40X50X20X639X450	40	20	450	50	639	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400200500	40X50X20X689X500	40	20	500	50	689	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250100	40X50X25X289X100	40	25	100	50	289	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250150	40X50X25X339X150	40	25	150	50	339	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250200	40X50X25X389X200	40	25	200	50	389	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250250	40X50X25X439X250	40	25	250	50	439	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250300	40X50X25X489X300	40	25	300	50	489	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250350	40X50X25X539X350	40	25	350	50	539	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250400	40X50X25X589X400	40	25	400	50	589	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250450	40X50X25X639X450	40	25	450	50	639	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250500	40X50X25X689X500	40	25	500	50	689	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250550	40X50X25X739X550	40	25	550	50	739	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0400250600	40X50X25X789X600	40	25	600	50	789	40	23	3/8”	16,2	40	20	35	34	25	16	56
ORK-FR0500250100	50X60X25X310X100	50	25	100	60	310	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250150	50X60X25X360X150	50	25	150	60	360	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250200	50X60X25X410X200	50	25	200	60	410	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250250	50X60X25X460X250	50	25	250	60	460	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250300	50X60X25X510X300	50	25	300	60	510	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250350	50X60X25X560X350	50	25	350	60	560	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250400	50X60X25X610X400	50	25	400	60	610	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250450	50X60X25X660X450	50	25	450	60	660	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250500	50X60X25X710X500	50	25	500	60	710	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250550	50X60X25X760X550	50	25	550	60	760	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250600	50X60X25X810X600	50	25	600	60	810	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500250800	50X60X25X1010X800	50	25	800	60	1010	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500251000	50X60X25X1210X1000	50	25	1000	60	1210	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300150	50X60X30X360X150	50	30	150	60	360	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300200	50X60X30X410X200	50	30	200	60	410	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300250	50X60X30X460X250	50	30	250	60	460	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300300	50X60X30X510X300	50	30	300	60	510	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300350	50X60X30X560X350	50	30	350	60	560	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300400	50X60X30X610X400	50	30	400	60	610	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300450	50X60X30X660X450	50	30	450	60	660	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300500	50X60X30X710X500	50	30	500	60	710	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300550	50X60X30X760X550	50	30	550	60	760	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300600	50X60X30X810X600	50	30	600	60	810	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300700	50X60X30X910X700	50	30	700	60	910	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500300800	50X60X30X1010X800	50	30	800	60	1010	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0500301000	50X60X30X1210X1000	50	30	1000	60	1210	43	26	3/8”	20,25	45	25	40	40	30	20	57
ORK-FR0600300100	60X70X30X340X100	60	30	100	70	340	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300150	60X70X30X390X150	60	30	150	70	390	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300200	60X70X30X440X200	60	30	200	70	440	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300250	60X70X30X490X250	60	30	250	70	490	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300300	60X70X30X540X300	60	30	300	70	540	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300350	60X70X30X590X350	60	30	350	70	590	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300400	60X70X30X640X400	60	30	400	70	640	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300450	60X70X30X690X450	60	30	450	70	690	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300500	60X70X30X740X500	60	30	500	70	740	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300550	60X70X30X790X550	60	30	550	70	790	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300600	60X70X30X840X600	60	30	600	70	840	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600300800	60X70X30X1040X800	60	30	800	70	1040	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600301000	60X70X30X1240X1000	60	30	1000	70	1240	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350100	60X70X35X340X100	60	35	100	70	340	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350150	60X70X35X390X150	60	35	150	70	390	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350200	60X70X35X440X200	60	35	200	70	440	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350250	60X70X35X490X250	60	35	250	70	490	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350300	60X70X35X540X300	60	35	300	70	540	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350350	60X70X35X590X350	60	35	350	70	590	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350400	60X70X35X640X400	60	35	400	70	640	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350450	60X70X35X690X450	60	35	450	70	690	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350500	60X70X35X740X500	60	35	500	70	740	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350550	60X70X35X790X550	60	35	550	70	790	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350600	60X70X35X840X600	60	35	600	70	840	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600350800	60X70X35X1040X800	60	35	800	70	1040	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600351000	60X70X35X1240X1000	60	35	1000	70	1240	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400200	60X70X40X440X200	60	40	200	70	440	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400250	60X70X40X490X250	60	40	250	70	490	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400300	60X70X40X540X300	60	40	300	70	540	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400350	60X70X40X590X350	60	40	350	70	590	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400400	60X70X40X640X400	60	40	400	70	640	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400450	60X70X40X690X450	60	40	450	70	690	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400500	60X70X40X740X500	60	40	500	70	740	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400550	60X70X40X790X550	60	40	550	70	790	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400600	60X70X40X840X600	60	40	600	70	840	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600400800	60X70X40X1040X800	60	40	800	70	1040	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0600401000	60X70X40X1240X1000	60	40	1000	70	1240	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400200	63X75X40X440X200	63	40	200	75	440	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400250	63X75X40X490X250	63	40	250	75	490	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400300	63X75X40X540X300	63	40	300	75	540	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400350	63X75X40X590X350	63	40	350	75	590	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400400	63X75X40X640X400	63	40	400	75	640	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400450	63X75X40X690X450	63	40	450	75	690	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400500	63X75X40X740X500	63	40	500	75	740	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400550	63X75X40X790X550	63	40	550	75	790	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400600	63X75X40X840X600	63	40	600	75	840	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630400800	63X75X40X1040X800	63	40	800	75	1040	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0630401000	63X75X40X1240X1000	63	40	1000	75	1240	50	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350100	70X80X35X340X100	70	35	100	80	340	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350150	70X80X35X390X150	70	35	150	80	390	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350200	70X80X35X440X200	70	35	200	80	440	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350250	70X80X35X490X250	70	35	250	80	490	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350300	70X80X35X540X300	70	35	300	80	540	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350350	70X80X35X590X350	70	35	350	80	590	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350400	70X80X35X640X400	70	35	400	80	640	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350450	70X80X35X690X450	70	35	450	80	690	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350500	70X80X35X740X500	70	35	500	80	740	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350550	70X80X35X790X550	70	35	550	80	790	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350600	70X80X35X840X600	70	35	600	80	840	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700350800	70X80X35X1040X800	70	35	800	80	1040	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700351000	70X80X35X1240X1000	70	35	1000	80	1240	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400200	70X80X40X440X200	70	40	200	80	440	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400250	70X80X40X490X250	70	40	250	80	490	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400300	70X80X40X540X300	70	40	300	80	540	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400350	70X80X40X590X350	70	40	350	80	590	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400400	70X80X40X640X400	70	40	400	80	640	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400450	70X80X40X690X450	70	40	450	80	690	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400500	70X80X40X740X500	70	40	500	80	740	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400550	70X80X40X790X550	70	40	550	80	790	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400600	70X80X40X840X600	70	40	600	80	840	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700400800	70X80X40X1040X800	70	40	800	80	1040	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0700401000	70X80X40X1240X1000	70	40	1000	80	1240	65	30	3/8”	25,25	50	30	50	45	35	25	68
ORK-FR0800400200	80X90X40X475X200	80	40	200	90	475	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800400250	80X90X40X525X250	80	40	250	90	525	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800400300	80X90X40X575X300	80	40	300	90	575	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800400400	80X90X40X675X400	80	40	400	90	675	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800400500	80X90X40X775X500	80	40	500	90	775	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800400600	80X90X40X875X600	80	40	600	90	875	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800400800	80X90X40X1075X800	80	40	800	90	1075	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800401000	80X90X40X1275X1000	80	40	1000	90	1275	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500200	80X90X50X475X200	80	50	200	90	475	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500250	80X90X50X525X250	80	50	250	90	525	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500300	80X90X50X575X300	80	50	300	90	575	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500400	80X90X50X675X400	80	50	400	90	675	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500500	80X90X50X775X500	80	50	500	90	775	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500600	80X90X50X875X600	80	50	600	90	875	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800500800	80X90X50X1075X800	80	50	800	90	1075	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0800501000	80X90X50X1275X1000	80	50	1000	90	1275	65	35	1/2”	30,25	60	35	60	50	45	30	75
ORK-FR0900500300	90X105X50X616X300	90	50	300	105	616	65	40	1/2”	40,25	70	40	80	70	60	40	93
ORK-FR0900500400	90X105X50X716X400	90	50	400	105	716	65	40	1/2”	40,25	70	40	80	70	60	40	93
ORK-FR0900500500	90X105X50X816X500	90	50	500	105	816	65	40	1/2”	40,25	70	40	80	70	60	40	93
ORK-FR0900500600	90X105X50X916X600	90	50	600	105	916	65	40	1/2”	40,25	70	40	80	70	60	40	93
ORK-FR0900500800	90X105X50X1116X800	90	50	800	105	1116	65	40	1/2”	40,25	70	40	80	70	60	40	93
ORK-FR0900501000	90X105X50X1316X1000	90	50	1000	105	1316	65	40	1/2”	40,25	70	40	80	70	60	40	93
ORK-FR1000500200	100X115X50X540X200	100	50	200	115	540	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000500250	100X115X50X590X250	100	50	250	115	590	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000500300	100X115X50X640X300	100	50	300	115	640	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000500400	100X115X50X740X400	100	50	400	115	740	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000500500	100X115X50X840X500	100	50	500	115	840	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000500600	100X115X50X940X600	100	50	600	115	940	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000500800	100X115X50X1140X800	100	50	800	115	1140	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000501000	100X115X50X1340X1000	100	50	1000	115	1340	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000600300	100X115X60X640X300	100	60	300	115	640	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000600400	100X115X60X740X400	100	60	400	115	740	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000600500	100X115X60X840X500	100	60	500	115	840	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000600600	100X115X60X940X600	100	60	600	115	940	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000600800	100X115X60X1140X800	100	60	800	115	1140	82	38	1/2”	40,25	70	40	80	70	60	40	95
ORK-FR1000601000	100X115X60X1340X1000	100	60	1000	115	1340	82	38	1/2”	40,25	70	40	80	70	60	40	95

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie FL 30

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	I	IF	M	N	ØO	ØLF	CH	ØP
ORK-FL0400200100	40X50X20X250X100	40	20	100	50	250	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FL0400200200	40X50X20X350X200	40	20	200	50	350	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FL0400200300	40X50X20X450X300	40	20	300	50	450	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FL0400200400	40X50X20X550X400	40	20	400	50	550	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FL0400200500	40X50X20X650X500	40	20	500	50	650	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FL0500300100	50X60X30X270X100	50	30	100	60	270	43	25	3/8”	18	40	M20 x1,5	14	128	105	26	ø13x4
ORK-FL0500300200	50X60X30X370X200	50	30	200	60	370	43	25	3/8”	18	40	M20 x1,5	14	128	105	26	ø13x4
ORK-FL0500300300	50X60X30X470X300	50	30	300	60	470	43	25	3/8”	18	40	M20 x1,5	14	128	105	26	ø13x4
ORK-FL0500300400	50X60X30X570X400	50	30	400	60	570	43	25	3/8”	18	40	M20 x1,5	14	128	105	26	ø13x4
ORK-FL0500300500	50X60X30X670X500	50	30	500	60	670	43	25	3/8”	18	40	M20 x1,5	14	128	105	26	ø13x4
ORK-FL0600350100	60X70X35X300X100	60	35	100	70	300	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FL0600350200	60X70X35X400X200	60	35	200	70	400	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FL0600350300	60X70X35X500X300	60	35	300	70	500	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FL0600350400	60X70X35X600X400	60	35	400	70	600	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FL0600350500	60X70X35X700X500	60	35	500	70	700	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FL0700400100	70X80X40X312X100	70	40	100	80	312	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FL0700400200	70X80X40X412X200	70	40	200	80	412	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FL0700400300	70X80X40X512X300	70	40	300	80	512	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FL0700400400	70X80X40X612X400	70	40	400	80	612	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FL0700400500	70X80X40X712X500	70	40	500	80	712	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FL0800500100	80X95X50X345X100	80	50	100	95	345	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FL0800500200	80X95X50X445X200	80	50	200	95	445	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FL0800500300	80X95X50X545X300	80	50	300	95	545	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FL0800500400	80X95X50X645X400	80	50	400	95	645	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FL0800500500	80X95X50X745X500	80	50	500	95	745	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FL1000500100	100X115X50X375X100	100	50	100	115	375	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FL1000500200	100X115X50X475X200	100	50	200	115	475	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FL1000500300	100X115X50X575X300	100	50	300	115	575	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FL1000500400	100X115X50X675X400	100	50	400	115	675	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FL1000500500	100X115X50X775X500	100	50	500	115	775	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie TS 15

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F	G	S
ORK-TS0400300200	40X50X30X326X200	40	30	200	50	326	23	3/8”	40
ORK-TS0400300250	40X50X30X376X250	40	30	250	50	376	23	3/8”	40
ORK-TS0400300300	40X50X30X426X300	40	30	300	50	426	23	3/8”	40
ORK-TS0400300350	40X50X30X476X350	40	30	350	50	476	23	3/8”	40
ORK-TS0400300400	40X50X30X526X400	40	30	400	50	526	23	3/8”	40
ORK-TS0400300500	40X50X30X626X500	40	30	500	50	626	23	3/8”	40
ORK-TS0500400200	50X60X40X338X200	50	40	200	60	338	26	3/8”	45
ORK-TS0500400300	50X60X40X438X300	50	40	300	60	438	26	3/8”	45
ORK-TS0500400400	50X60X40X538X400	50	40	400	60	538	26	3/8”	45
ORK-TS0500400500	50X60X40X638X500	50	40	500	60	638	26	3/8”	45
ORK-TS0500400600	50X60X40X738X600	50	40	600	60	738	26	3/8”	45
ORK-TS0600500300	60X70X50X450X300	60	50	300	70	450	30	3/8”	50
ORK-TS0600500400	60X70X50X550X400	60	50	400	70	550	30	3/8”	50
ORK-TS0600500500	60X70X50X650X500	60	50	500	70	650	30	3/8”	50
ORK-TS0600500600	60X70X50X750X600	60	50	600	70	750	30	3/8”	50

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie TH 22

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F	G	S	ØB1	ØJ	S1	S2
ORK-TH0300250100	30X40X25X190X100	30	25	100	40	190	40	3/8”	24	22	14	35	38
ORK-TH0300250150	30X40X25X240X150	30	25	150	40	240	40	3/8”	24	22	14	35	38
ORK-TH0300250200	30X40X25X290X200	30	25	200	40	290	40	3/8”	24	22	14	35	38
ORK-TH0300250250	30X40X25X340X250	30	25	250	40	340	40	3/8”	24	22	14	35	38
ORK-TH0300250300	30X40X25X390X300	30	25	300	40	390	40	3/8”	24	22	14	35	38
ORK-TH0400300200	40X50X30X300X200	40	30	200	50	300	42	3/8”	26	27	16	37	42
ORK-TH0400300250	40X50X30X350X250	40	30	250	50	350	42	3/8”	26	27	16	37	42
ORK-TH0400300300	40X50X30X400X300	40	30	300	50	400	42	3/8”	26	27	16	37	42
ORK-TH0400300350	40X50X30X450X350	40	30	350	50	450	42	3/8”	26	27	16	37	42
ORK-TH0400300400	40X50X30X500X400	40	30	400	50	500	42	3/8”	26	27	16	37	42
ORK-TH0400300550	40X50X30X650X550	40	30	550	50	650	42	3/8”	26	27	16	37	42
ORK-TH0500400200	50X60X40X330X200	50	40	200	60	330	47	3/8”	32	37	23	49	54
ORK-TH0500400250	50X60X40X380X250	50	40	250	60	380	47	3/8”	32	37	23	49	54
ORK-TH0500400300	50X60X40X430X300	50	40	300	60	430	47	3/8”	32	37	23	49	54
ORK-TH0500400350	50X60X40X480X350	50	40	350	60	480	47	3/8”	32	37	23	49	54
ORK-TH0500400400	50X60X40X530X400	50	40	400	60	530	47	3/8”	32	37	23	49	54
ORK-TH0500400550	50X60X40X680X550	50	40	550	60	680	47	3/8”	32	37	23	49	54
ORK-TH0500400700	50X60X40X830X700	50	40	700	60	830	47	3/8”	32	37	23	49	54
ORK-TH0600500300	60X70X50X460X300	60	50	300	70	460	50	3/8”	49	47	25,5	65	74
ORK-TH0600500400	60X70X50X560X400	60	50	400	70	560	50	3/8”	49	47	25,5	65	74
ORK-TH0600500550	60X70X50X710X550	60	50	550	70	710	50	3/8”	49	47	25,5	65	74
ORK-TH0600500700	60X70X50X860X700	60	50	700	70	860	50	3/8”	49	47	25,5	65	74

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie FA 30

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	I	IF	M	N	ØO	ØLF	CH	ØP
ORK-FA0400200100	40X50X20X250X100	40	20	100	50	250	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FA0400200200	40X50X20X350X200	40	20	200	50	350	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FA0400200300	40X50X20X450X300	40	20	300	50	450	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FA0400200400	40X50X20X550X400	40	20	400	50	550	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FA0400200500	40X50X20X650X500	40	20	500	50	650	40	25	3/8”	18	30	M16 x1,5	12	109	87	18	ø11x4
ORK-FA0500300100	50X60X30X270X100	50	30	100	60	270	43	25	3/8”	18	40	M20x 1,5	14	128	105	26	ø13x4
ORK-FA0500300200	50X60X30X370X200	50	30	200	60	370	43	25	3/8”	18	40	M20x 1,5	14	128	105	26	ø13x4
ORK-FA0500300300	50X60X30X470X300	50	30	300	60	470	43	25	3/8”	18	40	M20x 1,5	14	128	105	26	ø13x4
ORK-FA0500300400	50X60X30X570X400	50	30	400	60	570	43	25	3/8”	18	40	M20x 1,5	14	128	105	26	ø13x4
ORK-FA0500300500	50X60X30X670X500	50	30	500	60	670	43	25	3/8”	18	40	M20x 1,5	14	128	105	26	ø13x4
ORK-FA0600350100	60X70X35X300X100	60	35	100	70	300	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FA0600350200	60X70X35X400X200	60	35	200	70	400	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FA0600350300	60X70X35X500X300	60	35	300	70	500	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FA0600350400	60X70X35X600X400	60	35	400	70	600	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FA0600350500	60X70X35X700X500	60	35	500	70	700	50	30	3/8”	20	50	M27 x2	16	142	117	32	ø13x4
ORK-FA0700400100	70X80X40X312X100	70	40	100	80	312	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FA0700400200	70X80X40X412X200	70	40	200	80	412	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FA0700400300	70X80X40X512X300	70	40	300	80	512	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FA0700400400	70X80X40X612X400	70	40	400	80	612	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FA0700400500	70X80X40X712X500	70	40	500	80	712	67	30	3/8”	22	60	M30 x2	16	162	127	36	ø15x4
ORK-FA0800500100	80X95X50X345X100	80	50	100	95	345	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FA0800500200	80X95X50X445X200	80	50	200	95	445	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FA0800500300	80X95X50X545X300	80	50	300	95	545	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FA0800500400	80X95X50X645X400	80	50	400	95	645	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FA0800500500	80X95X50X745X500	80	50	500	95	745	65	40	1/2”	25	70	M36 x2	18	181	149	45	ø17x6
ORK-FA1000500100	100X115X50X375X100	100	50	100	115	375	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FA1000500200	100X115X50X475X200	100	50	200	115	475	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FA1000500300	100X115X50X575X300	100	50	300	115	575	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FA1000500400	100X115X50X675X400	100	50	400	115	675	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6
ORK-FA1000500500	100X115X50X775X500	100	50	500	115	775	85	40	1/2”	27	70	M36 x2	24	194	162	45	ø17x6

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Cilindro hidráulico — serie TC 121

Pedir presupuesto

Código	Producto	ØA mm	ØB mm	C mm	ØD mm	E mm	F1	F2	G	ØJ	K	L	Q	M	S
ORK-TC0500300150	50X60X30X463X150	50	30	150	60	463	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300200	50X60X30X513X200	50	30	200	60	513	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300250	50X60X30X563X250	50	30	250	60	563	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300300	50X60X30X613X300	50	30	300	60	613	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300350	50X60X30X663X350	50	30	350	60	663	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300400	50X60X30X713X400	50	30	400	60	713	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300450	50X60X30X763X450	50	30	450	60	763	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300500	50X60X30X813X500	50	30	500	60	813	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300550	50X60X30X863X550	50	30	550	60	863	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300600	50X60X30X913X600	50	30	600	60	913	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300700	50X60X30X1013X700	50	30	700	60	1013	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500300800	50X60X30X1113X800	50	30	800	60	1113	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0500301000	50X60X30X1313X1000	50	30	1000	60	1313	45	20	3/8”	19,2	62	44	62	115	133
ORK-TC0600300100	60X70X30X440X100	60	30	100	70	440	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300150	60X70X30X490X150	60	30	150	70	490	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300200	60X70X30X540X200	60	30	200	70	540	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300250	60X70X30X590X250	60	30	250	70	590	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300300	60X70X30X640X300	60	30	300	70	640	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300350	60X70X30X690X350	60	30	350	70	690	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300400	60X70X30X740X400	60	30	400	70	740	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300450	60X70X30X790X450	60	30	450	70	790	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300500	60X70X30X840X500	60	30	500	70	840	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300550	60X70X30X890X550	60	30	550	70	890	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300600	60X70X30X940X600	60	30	600	70	940	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600300800	60X70X30X1140X800	60	30	800	70	1140	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600301000	60X70X30X1340X1000	60	30	1000	70	1340	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350100	60X70X35X440X100	60	35	100	70	440	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350150	60X70X35X490X150	60	35	150	70	490	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350200	60X70X35X540X200	60	35	200	70	540	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350250	60X70X35X590X250	60	35	250	70	590	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350300	60X70X35X640X300	60	35	300	70	640	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350350	60X70X35X690X350	60	35	350	70	690	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350400	60X70X35X740X400	60	35	400	70	740	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350450	60X70X35X790X450	60	35	450	70	790	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350500	60X70X35X840X500	60	35	500	70	840	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350550	60X70X35X890X550	60	35	550	70	890	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350600	60X70X35X940X600	60	35	600	70	940	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600350800	60X70X35X1140X800	60	35	800	70	1140	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600351000	60X70X35X1340X1000	60	35	1000	70	1340	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400200	60X70X40X540X200	60	40	200	70	540	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400250	60X70X40X590X250	60	40	250	70	590	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400300	60X70X40X640X300	60	40	300	70	640	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400350	60X70X40X690X350	60	40	350	70	690	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400400	60X70X40X740X400	60	40	400	70	740	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400450	60X70X40X790X450	60	40	450	70	790	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400500	60X70X40X840X500	60	40	500	70	840	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400550	60X70X40X890X550	60	40	550	70	890	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400600	60X70X40X940X600	60	40	600	70	940	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600400800	60X70X40X1140X800	60	40	800	70	1140	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0600401000	60X70X40X1340X1000	60	40	1000	70	1340	55	25	3/8”	25,4	75	51	65	115	138
ORK-TC0630400200	63X75X40X540X200	63	40	200	75	540	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400250	63X75X40X590X250	63	40	250	75	590	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400300	63X75X40X640X300	63	40	300	75	640	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400350	63X75X40X690X350	63	40	350	75	690	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400400	63X75X40X740X400	63	40	400	75	740	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400450	63X75X40X790X450	63	40	450	75	790	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400500	63X75X40X840X500	63	40	500	75	840	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400550	63X75X40X890X550	63	40	550	75	890	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400600	63X75X40X940X600	63	40	600	75	940	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630400800	63X75X40X1140X800	63	40	800	75	1140	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0630401000	63X75X40X1340X1000	63	40	1000	75	1340	55	30	3/8”	25,4	75	51	65	115	138
ORK-TC0700350100	70X80X35X440X100	70	35	100	80	440	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350150	70X80X35X490X150	70	35	150	80	490	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350200	70X80X35X540X200	70	35	200	80	540	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350250	70X80X35X590X250	70	35	250	80	590	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350300	70X80X35X640X300	70	35	300	80	640	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350350	70X80X35X690X350	70	35	350	80	690	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350400	70X80X35X740X400	70	35	400	80	740	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350450	70X80X35X790X450	70	35	450	80	790	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350500	70X80X35X840X500	70	35	500	80	840	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350550	70X80X35X890X550	70	35	550	80	890	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350600	70X80X35X940X600	70	35	600	80	940	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700350800	70X80X35X1140X800	70	35	800	80	1140	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700351000	70X80X35X1340X1000	70	35	1000	80	1340	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400200	70X80X40X540X200	70	40	200	80	540	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400250	70X80X40X590X250	70	40	250	80	590	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400300	70X80X40X640X300	70	40	300	80	640	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400350	70X80X40X690X350	70	40	350	80	690	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400400	70X80X40X740X400	70	40	400	80	740	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400450	70X80X40X790X450	70	40	450	80	790	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400500	70X80X40X840X500	70	40	500	80	840	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400550	70X80X40X890X550	70	40	550	80	890	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400600	70X80X40X940X600	70	40	600	80	940	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700400800	70X80X40X1140X800	70	40	800	80	1140	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0700401000	70X80X40X1340X1000	70	40	1000	80	1340	65	22	3/8”	25,4	75	51	65	115	138
ORK-TC0800400200	80X90X40X600X200	80	40	200	90	600	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800400250	80X90X40X650X250	80	40	250	90	650	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800400300	80X90X40X700X300	80	40	300	90	700	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800400400	80X90X40X800X400	80	40	400	90	800	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800400500	80X90X40X900X500	80	40	500	90	900	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800400600	80X90X40X1000X600	80	40	600	90	1000	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800400800	80X90X40X1200X800	80	40	800	90	1200	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800401000	80X90X40X1400X1000	80	40	1000	90	1400	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500200	80X90X50X600X200	80	50	200	90	600	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500250	80X90X50X650X250	80	50	250	90	650	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500300	80X90X50X700X300	80	50	300	90	700	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500400	80X90X50X800X400	80	50	400	90	800	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500500	80X90X50X900X500	80	50	500	90	900	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500600	80X90X50X1000X600	80	50	600	90	1000	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800500800	80X90X50X1200X800	80	50	800	90	1200	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0800501000	80X90X50X1400X1000	80	50	1000	90	1400	65	35	1/2”	32,4	85	51	65	155	180
ORK-TC0900500300	90X105X50X715X300	90	50	300	105	715	65	27	1/2”	40,2 - 32,4	105	75	85	155	178
ORK-TC0900500400	90X105X50X815X400	90	50	400	105	815	65	27	1/2”	40,2 - 32,4	105	75	85	155	178
ORK-TC0900500500	90X105X50X915X500	90	50	500	105	915	65	27	1/2”	40,2 - 32,4	105	75	85	155	178
ORK-TC0900500600	90X105X50X1015X600	90	50	600	105	1015	65	27	1/2”	40,2 - 32,4	105	75	85	155	178
ORK-TC0900500800	90X105X50X1215X800	90	50	800	105	1215	65	27	1/2”	40,2 - 32,4	105	75	85	155	178
ORK-TC0900501000	90X105X50X1415X1000	90	50	1000	105	1415	65	27	1/2”	40,2 - 32,4	105	75	85	155	178
ORK-TC1000500200	100X115X50X630X200	100	50	200	115	630	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000500250	100X115X50X680X250	100	50	250	115	680	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000500300	100X115X50X730X300	100	50	300	115	730	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000500400	100X115X50X830X400	100	50	400	115	830	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000500500	100X115X50X930X500	100	50	500	115	930	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000500600	100X115X50X1030X600	100	50	600	115	1030	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000500800	100X115X50X1230X800	100	50	800	115	1230	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000501000	100X115X50X1430X1000	100	50	1000	115	1430	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000600300	100X115X60X730X300	100	60	300	115	730	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000600400	100X115X60X830X400	100	60	400	115	830	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000600500	100X115X60X930X500	100	60	500	115	930	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000600600	100X115X60X1030X600	100	60	600	115	1030	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000600800	100X115X60X1230X800	100	60	800	115	1230	80	31	1/2”	40,2 - 32,4	105	75	85	155	180
ORK-TC1000601000	100X115X60X1430X1000	100	60	1000	115	1430	80	31	1/2”	40,2 - 32,4	105	75	85	155	180

Todas las medidas en mm salvo indicación. Las medidas no listadas se fabrican según plano o muestra.

Presupuesto y contacto

Pedir presupuesto

Envíe plano, muestra o medidas: analizamos la fabricabilidad y preparamos el presupuesto.

Teléfono+90 530 140 16 34
Llamar / SMS+90 530 140 16 34
WhatsAppEnvíenos un mensaje →
Infoinfo@orksemengineering.com
Salessales@orksemengineering.com.tr
Muhasebemuhasebe@orksemengineering.com.tr

Osmangazi Mah. Vefa Sk. No: 13-15, TURKEY
Lun – Sáb · 9:00 – 18:00 (GMT+3)

Nombre y apellidos *

Correo electrónico *

Teléfono

Asunto

Su solicitud *

Escríbenos por WhatsApp →
